型號： 0039014053
廠商： MOLEX INC
元件分類： 電源輸入模塊
英文描述： 5 CONTACT(S), MALE, POWER CONNECTOR, CRIMP, PLUG
封裝： HALOGEN FREE AND ROHS COMPLIANT
文件頁數： 3/4頁
文件大?。?/td> 152K
代理商： 0039014053
General
Product Family
Crimp Housings
Series
5559
Comments
Current = 13A max. per circuit when header is mated to a
receptacle loaded with 45750 series terminals crimped to 16
AWG wire.
See Molex product specification PS-45750-001 for additional
current de-rating information.
Overview
Mini-Fit Jr.
Product Name
Mini-Fit Jr.
Physical
Breakaway
No
Circuits (maximum)
5
Color - Resin
Natural
Flammability
94V-0
Gender
Male
Glow-Wire Compliant
No
Keying to Mating Part
None
Lock to Mating Part
Yes
Material - Resin
Nylon
Number of Rows
1
Packaging Type
Bag
Panel Mount
Yes
Pitch - Mating Interface (in)
0.165 In
Pitch - Mating Interface (mm)
4.20 mm
Pitch - Term. Interface (in)
0.165 In
Pitch - Term. Interface (mm)
4.20 mm
Polarized to Mating Part
Yes
Stackable
No
Temperature Range - Operating
-40°C to +105°C
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
13A
Agency Certification
CSA
LR19980
TUV
R72081037
UL
E29179
Material Info
Old Part Number
5559-05P2-210
Molex Connector Part Number - 0039014053
Page 3 of 4
C:\TEMP\04192010\MOLE\0039014053.mht
20-Apr-2010
