| 型號： | 0193220000 |
| 廠商： | WEIDMULLER |
| 元件分類： | 接線盒 |
| 英文描述： | 47 A, MODULAR TERMINAL BLOCK, 1 ROW, 1 DECK |
| 文件頁數： | 2/4頁 |
| 文件大?。?/td> | 75K |
| 代理商： | 0193220000 |
Product catalogue | Terminals | Screwing technology | SAK-series modular terminals | TS 32 | Germin KrG | Modular
feed-through terminals | 6 mm
- 2 -
Additional technical data
Insulating material
KrG
Levels cross-connected internally
No
No. of identical terminals
1
No. of levels
1
No. of terminal strips per level
2
Open sides
right
Operating temperature range
- 60 °C, + 130 °C
Type of connection
Screwed
Type of mounting
Snap-on
UL 94 flammability rating of insulation material
5VA
Version
Feed-through terminal
CSA rating data
Voltage (CSA)
600 V
CSA current
47 A
Min. cross-section (CSA)
AWG 20
Max. cross-section (CSA)
AWG 8
Conductors for clamping (additional
connection)
Flexible with ferrule, min. (DIN 46228 pt 1)
0.5 mm
Flexible with ferrule, max. (DIN 46228 pt 1)
6 mm
Conductors for clamping (rated connection)
Clamping range, min.
0.33 mm
Clamping range, max.
10 mm
Type of connection
Screw connection
2nd type of connection
screwed
Connection direction
on side
No. of connections
2
Stripping length
12 mm
Clamping screw
M 3.5
Blade size
4.0 x 0.8 mm
Tightening torque range
0.8...1.6 Nm
Torque level with DMS electric screwdriver
3
Gauge to IEC 60947-1
A5
Solid, min.
0.5 mm
Solid, max.
10 mm
Stranded, min.
0.5 mm
Stranded, max.
6 mm
Flexible, min.
0.5 mm
Flexible, max.
10 mm
Flexible with ferrule, min. (DIN 46228/1)
0.5 mm
Flexible with ferrule, max. (DIN 46228/1)
6 mm
Flexible, min., ferrule with plastic collar (DIN
46228 pt 4)
0.5 mm
Flexible, max., ferrule with plastic collar (DIN
46228 pt 4)
6 mm
Twin wire-end ferrule, min.
0.5 mm
Twin wire end ferrule, max.
4 mm
AWG conductor size, min.
AWG 22
