| 型號： | 0215580000 |
| 廠商： | WEIDMULLER |
| 元件分類： | 接線盒 |
| 英文描述： | 20 A, MODULAR TERMINAL BLOCK, 1 DECK |
| 文件頁數： | 2/3頁 |
| 文件大小： | 63K |
| 代理商： | 0215580000 |
Product catalogue | Terminals | Screwing technology | SAK-series modular terminals | TS 32 | Polyamide PA 6.6 |
Modular feed-through terminals | 2.5 mm
- 2 -
Conductors for clamping (rated connection)
Tightening torque range
0.4...0.6 Nm
Torque level with DMS electric screwdriver
1
Gauge to IEC 60947-1
A2
Solid, min.
0.5 mm
Solid, max.
4 mm
Stranded, min.
0.5 mm
Stranded, max.
2.5 mm
Flexible, min.
0.5 mm
Flexible, max.
4 mm
Flexible with ferrule, min. (DIN 46228/1)
0.5 mm
Flexible with ferrule, max. (DIN 46228/1)
2.5 mm
Flexible, min., ferrule with plastic collar (DIN
46228 pt 4)
0.5 mm
Flexible, max., ferrule with plastic collar (DIN
46228 pt 4)
1.5 mm
Twin wire-end ferrule, min.
0.5 mm
Twin wire end ferrule, max.
1 mm
AWG conductor size, min.
AWG 28
AWG conductor size, max.
AWG 12
AWG conductor size, min.
0.08 mm
AWG conductor size, max.
3.31 mm
Dimensions
Width
5 mm
Height of lowest version
43.5 mm
Length
32.5 mm
TS 32 offset
16 mm
Disconnect terminals
Torque level with DMS electric screwdriver
1
Rating data
Rated cross-section
2.5 mm
Rated voltage
500 V
Rated impulse voltage
6 kV
Rated current
24 A
Standards
IEC 60947-7-1
Current with max. conductor
30 A
Pollution severity
3
UL rating data
Voltage (UL)
300 V
Current (UL)
20 A
Min. cross-section (UL)
AWG 28
Max. cross-section (UL)
AWG 12
