Characteristics and dimensions of terminals
Part number
03526.311.011
Specification
Cable lug ring type
Material
SE-Cu
Surface / Colour
Sn 3
Form
Single form
Single part
X
Packing unit /
piece
150
Section area
(mm2)
35.00
DIN
hnlich 46211 Form
A
Nominal size
10x8.2
Material thickness
(mm)
1.50
a1
16.00
d2
10.50
d3
19.00
l1
35.00
Note: The drawing only gives an overview of the geometry of the part. The crimp area is shown as
supplied in strip form. A technical drawing is available on request.
Packing Units (per 150 pieces)
CW
