This document was generated on 12/10/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Description:
OBD-II Crimp Terminal, Female, 50420, 4.00mm (.157") Pitch
Documents:
General
Product Family
Crimp Terminals
Series
Product Name
OBD-II
Physical
Gender
Female
Material - Metal
Phosphor Bronze
Material - Plating Mating
Tin
Material - Plating Termination
Tin
Packaging Type
Reel
Termination Interface: Style
Crimp or Compression
Wire Insulation Diameter
1.60-2.30mm (.024-.091")
Wire Size AWG
N/A
Wire Size mm
AVS 0.30 TO 0.85
Wire Size mm
AVS 0.30F TO 0.75F
Wire Size mm
AVSS 0.50 TO 0.85
Wire Size mm
AVSS 0.50F TO 0.75F
Wire Size mm
CAVS 0.50 TO 0.85
Material Info
Reference - Drawing Numbers
Product Specification
PS-51115-001
Sales Drawing
SD-50420-8*00
Series image - Reference only
ELV and RoHS
Compliant
Contains SVHC: No
Halogen-Free
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
50420 Series
Use With
Application Tooling
| FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Fine Adjust
Applicator for
OBD II 4.00mm
(.157") Wire-to-Wire
Crimp Terminal,
0.30-0.85mm2 and
18-22 AWG
Extraction Tool
Hand Crimp Tool
Mini-Mac Fully
Tooled
Japan
Description
Product #
