TECHNICAL DATA SHEET
RPC-N
MISMATCH PLUG
05S150-060S3
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
RF_35/12.04/3.0
Electrical data
Impedance
60
Frequency
DC to 18 GHz
VSWR
1.2
± 0.04, DC to 8 GHz
1.2
± 0.05, 8 GHz to 12.4 GHz
1.2
± 0.07, 12.4 GHz to 18 GHz
Center contact resistance
≤ 1.0 m
Outer contact resistance
≤ 1.0 m
Power handling
1 W at 25°C
derated linearity by 0.01 W/K
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 28 N
Coupling test torque
1.70 Nm
Recommended torque
0.70 Nm to 1.10 Nm
Environmental data
Temperature range
-40°C to +85°C
Tooling
N/A
Suitable cables
N/A
Packing
Standard
1 pce in bag
Weight
50.0 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Kerstin Herzog
12/07/04
Andreas Burkert
14/12/04
a00
04-0130
Frank Wei
15/03/05
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
