Product catalogue | Terminals | Screwing technology | SAK-series modular terminals | TS 32 | Polyamide PA 6.6 |
Modular terminals with electronic components | Diode terminals
- 1 -
General ordering data
Order No.
0663960000
Part designation
DK4D
Version
Component terminal, 4 mm, Screw connection,
PA 66, beige, TS 32
EAN
4008190147853
Qty.
25 pc(s).
Product notes
Note, technical data
Diode current: max 1A. (1 N 4007)
Function
Diodes terminal for lamp-test-circuits
Additional technical data
Colour of insulating material
beige
Connection direction
on side
End plate required
Yes
Explosion-tested version "Ex e"
No
Installation advice
TS 32
Insulating material
PA 66
Levels cross-connected internally
No
No. of identical terminals
1
No. of levels
2
No. of terminal strips per level
2
Open sides
right
Operating temperature range
- 50 °C, + 100 °C
Product family
SAK Series
Type of connection
Screwed
Type of mounting
Snap-on
UL 94 flammability rating of insulation material
V2
Version
Terminal with diode
CSA rating data
Voltage (CSA)
300 V
CSA current
10 A
Conductors for clamping (additional
connection)
Type of connection
Screw connection
Conductors for clamping (rated connection)
Clamping range, min.
0.33 mm
