This document was generated on 11/06/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Overview:
Description:
1.27mm (.050") Pitch Serial ATA Crimp Terminal for Power Cable Receptacle,
Unplated, with Reel Direction - Type 2, Lead free
Documents:
General
Product Family
Crimp Terminals
Series
Current - Maximum
1.5A
Overview
Serial ATA Products
Product Name
Serial ATA
Voltage - Maximum
15V DC
Physical
Durability (mating cycles max)
50
Gender
Female
Material - Metal
Phosphor Bronze
Material - Plating Mating
Unplated
Material - Plating Termination
Tin
Packaging Type
Reel
Plating min: Mating (in)
0
Plating min: Mating (m)
0
Plating min: Termination (in)
73.82
Plating min: Termination (m)
1.85
Termination Interface: Style
Crimp or Compression
Wire Insulation Diameter
2.20-1.60mm(0.087-0.063)
Wire Size AWG
18
Wire Size AWG
20
Wire Size AWG
22
Wire Size mm
3.79-2.00
Material Info
Reference - Drawing Numbers
Product Specification
PS-67490-002
Sales Drawing
SD-67581-001
Series image - Reference only
ELV and RoHS
Compliant
Contains SVHC: No
Not Reviewed
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
67581 Series
Use With
67582 Crimp Housing
This document was generated on 11/06/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
