264
10BQ015
Part number
V
R
Max. DC Reverse Voltage (V)
V
RWM
Max. Working Peak Reverse Voltage (V)
10BQ015
15
25
Parameters
Max.Junction Temperature Range
Max. Storage Temperature Range
Max. Thermal Resistance, Junction
to Ambient
Max. Thermal Resistance, Junction
to Lead
Approximate Weight
Case Style
10BQ
-55 to 100
-55 to 100
140
Units
°C
°C
°C/W
Conditions
T
J
T
STG
R
thJA
DC operation — See Fig. 4
R
thJL
36
°C/W
DC operation
wt
0.10
g
SMB
Similar to DO-214AA
Parameters
V
FM
Max. Forward Voltage Drop
See Fig. 1
10BQ
0.34
0.40
0.30
0.38
0.50
12
390
2.0
6,000
Units
V
V
V
V
mA
mA
pF
nH
V/μs
Conditions
@ 1.0A
@ 2.0A
@ 1.0A
@ 2.0A
T
J
= 25°C
T
J
= 100°C
V
R
= 5V
DC
, (test signal range 100KHz to 1MHz) 25°C
Measured lead to lead 5mm from package body
I
RM
Max. Reverse Leakage Current
See Fig. 2
Max. Junction Capacitance
Typical Series Inductance
Max. Voltage Rate of Change
(Rated V
R
)
C
T
L
S
dv/dt
Parameters
Max. Average Forward Current
See Fig. 5
Max. Peak One Cycle Non - Repetitive
Surge Current — see Fig. 7
Non - Repetitive Avalanche Energy
10BQ Units Conditions
1.0
A
I
F(AV)
50% duty cycle @ T
C
= 78°C, rectangular waveform
I
FSM
140
40
5.0
A
5μs Sine or 3μs Rect. pulse
10ms Sine 0r 6ms Rect. pulse
T
J
= 25°C, I
AS
= 0.2A, L = 4.2mH
Following any rated load condition
and with rated V
RRM
applied.
E
AS
mJ
I
AR
Repetitive Avalanche Current
0.2
A
Current decaying linearly to zero in 1μsec
Frequency limited by T
J
max. V
A
= 1.5 X V
R
typical
Voltage Ratings
Absolute Maximum Ratings
T
J
= 25°C
T
J
= 75°C
V
R
= rated V
R
Thermal-Mechanical Specifications
Electrical Specifications
Pulse Width < 300μs, Duty Cycle < 2%
Mounted 1 inch square PCB, thermal probe connected to lead 2mm from package
