10BQ060
Bulletin PD-2.438 rev. G 0
7
/04
5
www.irf.com
3.80 (.150)
3.30 (.130)
4.70 (.185)
4.10 (.161)
2.15 (.085)
1.80 (.071)
2.40 (.094)
1.90 (.075)
1.30 (.051)
0.76 (.030)
0.30 (.012)
0.15 (.006)
5.60 (.220)
5.00 (.197)
4.0 (.157)
2.0 TYP.
(.079 TYP.)
2.5 TYP.
(.098 TYP.)
SOLDERING PAD
CATHODE
ANODE
1
2
1
2
POLARITY
PART NUMBER
4.2 (.165)
IR LOGO
YYWWX
"Y" = 1st digit of the YEAR "standard product"
"P" = "Lead-Free"
2nd digit of the YEAR
SITE ID
WEEK
CURRENT
VOLTAGE
IR1H
Device Marking: IR1H
Dimensions in millimeters and (inches)
Outline SMB
For recommended footprint and soldering techniques refer to application note #AN-994
Outline Table
Marking & Identification
Each device has 2 rows for identification. The first row designates the device as manufactured by International
Rectifier, indicated by the letters "IR", and the Part Number (indicates the current, the voltage rating and
Schottky Generation). The second row indicates the year, the week of manufacturing and the Site ID.
