04-2011, Rev. 0411
2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
SCHRACK
General Purpose Relays
Power Relays
n
1 pole 16A, 1 form A (NO) contact
n
Safety mains isolation
n
Contact gap >3mm
n
DC and AC coil
n
4kV/8mm coil-contact, reinforced insulation (VDE 0700)
n
PCB mounting or quick connect terminals
n
Mounting brackets or snap mounting
n
Version with arc blow magnet for high DC loads
n
Product in accordance to IEC 60335-1
Typical applications
Domestic appliances, industrial appliances, industrial controls
Approvals
VDE REG.-Nr. C820, UL E214024
Technical data of approved types on request
Contact Data
Contact arrangement
Contact gap
Rated voltage
Max. switching voltage
Rated current
Limiting making current, max 4 s, duty factor 10% 25A
Breaking capacity max.
Contact material
Contact style
Frequency of operation, with/without load
1 form A (NO)
>3mm
250VAC
400VAC
16A
4000VA
AgCu3, AgCdO
bifurcated contact
900/18000h
-1
Contact ratings
Type
IEC 61810
0430 .4 .. 0
0430 .4 .. 1
Mechanical endurance
DC coil
AC coil
Contact Load
Cycles
A (NO) 16A, 250VAC, cos
φ
=1, 70°C
A (NO) 16A, 250VAC, cos
φ
=1, 70°C
50x103
50x103
>250x10
3
operations
>250x10
3
operations
Coil Data
Coil voltage range
DC coil
AC coil
Operative range, IEC 61810
6 to 110VDC
6 to 240VAC
2
Coil versions, DC coil
Coil
code
09
10
11
13
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Other coil voltages on request.
Coil versions, AC coil, 50Hz
Coil
Rated
Operate
code
voltage
voltage
VAC
VAC
23
24
18
25
60
45
26
110
83
27
230
175
28
240
185
All figures are given for coil without pre-energization, at ambient temperature +23°C, 50Hz.
Other coil voltages on request.
Rated
voltage
VDC
12
24
48
110
Operate
voltage
VDC
7.8
15.6
31.2
71.5
Release
voltage
VDC
0.6
1.2
2.4
5.5
Coil
Rated coil
power
mW
993
993
1047
931
resistance
±10%
145
580
2200
13000
Release
voltage
VAC
3.6
9
16
35
36
Coil
Rated coil
power
VA
1.8
1.8
1.8
1.8
1.8
resistance
±10%
145
950
3100
11400
13000
Insulation Data
Initial dielectric strength
between open contacts
between contact and coil
Clearance/creepage
between contact and coil
Material group of insulation parts
Tracking index of relay base
2000V
rms
4000V
rms
≥8/8mm
IIIa
PTI250
Power Relay 430 3mm
F0256-B
Z
V
