SCHEMATICS
Weight (in gram)
:
1.0 typ.
Tape& Reel
:
800/ reel
7. All dimensions are specified in
with higher precedence in inches.
inches
mm
.010
0.25
Notes:
8. U
±.
nless otherwise specified, all tolerances are
9. For available RoHS part number, the part will be marked with “XYYYF”, instead of “XYYY”.
.215
5.46 Max
.370
9.40
Max
.510
12.95 Max
Recommended
Pad Layout
.290
7.37
.115
2.92
.110
2.79
1
2
XYYY
(DATE)
MD
ECHANICAL
IMENSIONS
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
Tel: (852) 2765 3888
Fax: (852) 2954 3304
E&E Magnetic Products Limited
SMT POWER INDUCTORS
Drum Type, UIS3316 Series, Self-Leaded
Revised in 06/07
PI001(06)
