2SK2544
2009-09-29
2
Electrical Characteristics (Ta = 25°C)
Characteristics
Symbol
Test Condition
Min
Typ.
Max
Unit
Gate leakage current
IGSS
VGS = ±25 V, VDS = 0 V
—
±10
μA
Gatesource breakdown voltage
V (BR) GSS
IG = ±10 μA, VGS = 0 V
±30
—
V
Drain cutoff current
IDSS
VDS = 600 V, VDS = 0 V
—
100
μA
Drainsource breakdown voltage
V (BR) DSS
ID = 10 mA, VGS = 0 V
600
—
V
Gate threshold voltage
Vth
VDS = 10 V, ID = 1 mA
2.0
—
4.0
V
Drainsource ON resistance
RDS (ON)
VGS = 10 V, ID = 3 A
—
0.9
1.25
Forward transfer admittance
|Yfs|
VDS = 10 V, ID = 3 A
2.0
5.5
—
S
Input capacitance
Ciss
—
1300
—
Reverse transfer capacitance
Crss
—
130
—
Output capacitance
Coss
VDS = 10 V, VGS = 0 V, f = 1 MHz
—
400
—
pF
Rise time
tr
—
25
—
Turnon time
ton
—
45
—
Fall time
tf
—
40
—
Switching time
Turnoff time
toff
—
150
—
ns
Total gate charge (Gatesource
plus gatedrain)
Qg
—
30
—
Gatesource charge
Qgs
—
18
—
Gatedrain (“miller”) charge
Qgd
VDD ≈ 400 V, VGS = 10 V, ID = 6 A
—
12
—
nC
SourceDrain Ratings and Characteristics (Ta = 25°C)
Characteristics
Symbol
Test Condition
Min
Typ.
Max
Unit
Continuous drain reverse current
(Note 1)
IDR
—
6
A
Pulse drain reverse current
(Note 1)
IDRP
—
24
A
Forward voltage (diode)
VDSF
IDR = 6 A, VGS = 0 V
—
1.7
V
Reverse recovery time
trr
—
1000
—
ns
Reverse recovery charge
Qrr
IDR = 6 A, VGS = 0 V
dIDR / dt = 100 A / μs
—
7
—
μC
Marking
Lot No.
Note 4
K2544
Part No.
(or abbreviation code)
Note 4: A line under a Lot No. identifies the indication of product Labels.
Not underlined: [[Pb]]/INCLUDES > MCV
Underlined: [[G]]/RoHS COMPATIBLE or [[G]]/RoHS [[Pb]]
Please contact your TOSHIBA sales representative for details as to
environmental matters such as the RoHS compatibility of Product. The
RoHS is the Directive 2002/95/EC of the European Parliament and of the
Council of 27 January 2003 on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
