The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
MOS FIELD EFFECT TRANSISTOR
2SK3484
SWITCHING
N-CHANNEL POWER MOS FET
DATA SHEET
Document No. D15069EJ3V0DS00 (3rd edition)
Date Published August 2006 NS CP(K)
Printed in Japan
2002
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
DESCRIPTION
The 2SK3484 is N-channel MOS Field Effect Transistor
designed for high current switching applications.
FEATURES
Low on-state resistance
RDS(on)1 = 125 m
Ω MAX. (VGS = 10 V, ID = 8 A)
RDS(on)2 = 148 m
Ω MAX. (VGS = 4.5 V, ID = 8 A)
Low Ciss: Ciss = 900 pF TYP.
Built-in gate protection diode
TO-251/TO-252 package
ABSOLUTE MAXIMUM RATINGS (TA = 25°C)
Drain to Source Voltage (VGS = 0 V)
VDSS
100
V
Gate to Source Voltage (VDS = 0 V)
VGSS
±20
V
Drain Current (DC) (TC = 25°C)
ID(DC)
±16
A
Drain Current (pulse)
Note1
ID(pulse)
±22
A
Total Power Dissipation (TC = 25°C)
PT1
30
W
Total Power Dissipation (TA = 25°C)
PT2
1.0
W
Channel Temperature
Tch
150
°C
Storage Temperature
Tstg
–55 to +150
°C
Single Avalanche Current
Note2
IAS
10
A
Single Avalanche Energy
Note2
EAS
10
mJ
Notes 1. PW
≤ 10
μs, Duty Cycle ≤ 1%
2. Starting Tch = 25°C, VDD = 50 V, RG = 25 Ω, VGS = 20
→ 0 V
THERMAL RESISTANCE
Channel to Case Thermal Resistance
Rth(ch-C)
4.17
°C/W
Channel to Ambient Thermal Resistance
Rth(ch-A)
125
°C/W
(TO-251)
(TO-252)
ORDERING INFORMATION
PART NUMBER
PACKAGE
2SK3484
TO-251 (MP-3)
2SK3484-Z
TO-252 (MP-3Z)
