| 型號： | 2T63-266-1100-AF |
| 廠商： | HON HAI PRECISION INDUSTRY CO LTD |
| 元件分類： | 電路板相疊連接器 |
| 英文描述： | 266 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT |
| 封裝： | LEAD FREE |
| 文件頁數： | 1/1頁 |
| 文件大?。?/td> | 48K |
| 代理商： | 2T63-266-1100-AF |
All specification & dimensions are subject to change, please call your nearest Foxconn sales representative for update information.
SPECIFICATIONS
FOXTOR CONNECTOR
2T Series,
Exten der
0. 635mm [.025”] Pitch
1.062” M/H 26 6 Po s.
Mechanical
Mating Force: 3.0KG max per 12.7mm of connector
Unmating Force: 0.5KG min per 12.7mm of connector
Durability: 30 Cycles
Electrical
Voltage Raging: 30VAC
Current Rating: Signal 0.5A max per pin
Power 3.0A max per pin
Contact Resistance: 20m
max.
Insulation Resistance: 5000M
min.
Physical
Housing: LCP UL94V-0, Ivory White
Contact: Copper Alloy
Plating: See “ORDERING INFORMATION”
DRAWING
ORDERING INFORMATION
