Technical Data Sheet
Everlux (Solderless Power LED)
Preliminary
35-03UYC/S599
Everlight Electronics Co., Ltd.
http:\\www.everlight.com
Rev. 1
Page: 7 of 7
Device number:
Established date: 07-22-2005
Established by: Jonny, Lin
Reliability Data
1. Description
The following cumulative test results have been obtained from testing performed in accordance
with the latest revision of MIL_STD_883. Everlight tests parts at the absolute maximum rated
conditions recommended for the device. The actual performance you obtain depends on the electrical
and environmental characteristics of your application, but will probably be better than the
performance outlined in the table below.
2. Reliability Test
Test Item
Reference
Test Condition
Note
Steady State Operating
Life of High Ambient
Temperature
Internal Reference
Ta=55
oC
If=150mA
1000hrs.
High Temperature
Humidity Operating Test
JEITA ED-4701
100 103
Ta=60
oC, RH=90%
If=100mA
1000hrs.
Temperature Cycle
MIL-STD-883
Method 1010
-40
oC~120 oC, 15 min.
dwell, 5min transfer
200 cycles
Power Temperature Cycle
Internal Reference
-40
oC~85 oC, 18 min.
dwell, 42min. transfer,
150 mA, 5min. on/off
100 cycles
Pulse Test
Internal Reference
Ta=55
oC Pulse
50% Duty Factor, 2Hz
If=200mA
1000hrs.
3. Criteria for Judging the Damage
Item
Symbol
Test Condition
Criteria For Judgement
Forward Voltage
Vf
If=150mA
Vf difference < 10%
Total Flux
Φv
If=150mA
Brightness attenuate difference
(1000 hrs.)< 30%
EVERLIGHT ELECTRONICS CO., LTD.
Tel: 886-2-2267-2000, 2267-9936
Office: No 25, Lane 76, Sec 3, Chung Yang Rd,
Fax: 886-2267-6244, 2267-6189, 2267-6306
Tucheng, Taipei 236, Taiwan, R.O.C
http:\\www.everlight.com
