LOW POWER LOW OFFSET VOLTAGE DUAL COMPARATORS AZ393/393C
1
Aug. 2006 Rev. 1. 2
BCD Semiconductor Manufacturing Limited
Data Sheet
General Description
The AZ393/393C series consists of two independent
precision voltage comparators with an offset voltage
specification as low as 1mV. The input common mode
voltage range of these comparators includes ground,
even when operated from a single power supply volt-
age. Operation from split power supplies is also possi-
ble and the low power supply current drain is
independent of the magnitude of the power supply
voltage.
The AZ393/393C series is designed to directly inter-
face with TTL and CMOS. AZ393C has more
stringent input offset voltage than AZ393.
The AZ393/393C series can be widely used in applica-
tions such as battery charger, cordless telephone,
switching power supply, DC-DC module and PC
motherboard.
The AZ393/393C series are available in standard pack-
ages of DIP-8 and SOIC-8.
Features
·
- Single Supply: 2.0V to 18V
- Dual Supplies:
±1
.0V to
±
9V
·
Very Low Supply Current Drain: 0.4mA
- Independent of Supply Voltage
·
Low Input Bias Current: 25nA (Typical)
·
Low Input Offset Current:
±
5nA (Typical)
·
Low Input Offset Voltage:
±
1mV (Typical)
·
Input Common Mode Voltage Range Includes
Ground
·
Differential Input Voltage Range Equals to the
Power Supply Voltage
·
Low Output Saturation Voltage: 250mV at 4mA
·
Open Collector Output
Wide Supply Voltage Range
Applications
·
·
·
·
·
·
Battery Charger
Cordless Telephone
Switching Power Supply
DC-DC Module
PC Motherboard
Communication Equipment
Figure 1. Package Types of AZ393/393C
SOIC-8
DIP-8
