DATASHEET| MARCH 3, 2010
EMCORE CORPORATION
Model 3955 DFB 1550 nm Laser in TO-can
Absolute Maximum Ratings1
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only. Functional operation of the device is not implied at these or any other conditions in
excess of those given in the operational sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect device reliability.
Parameters
Symbol
Condition/Notes
MIN
MAX
Unit
Storage Temperature
TSTG
Non-Operating
-40
85
oC
Operating Case Temperature
TOP
Continuous
-40
85
oC
Laser Diode Forward Current
IOP
CW
-
150
mA
Laser Diode Reverse Voltage
VR
Continuous
-
1.0
V
Photodiode Forward Current
IMPD
Continuous
-
2
mA
Photodiode Reverse Voltage
VMPD,R
Continuous
-
10
V
Average RF Input Power
PIN
60 Seconds
-
62
dBmV
Lead Soldering Temperature/Time
-
260/10
oC/sec
Relative Humidity
RH
Continuous
-
85
%
ESD
-
Human Body Model
-500
+500
V
1.
Absolute maximum data are limited to system design only; proper device performance is not guaranteed over rating listed above. Operation
beyond these maximum conditions may degrade device performance, lead to device failure, shorter lifetime, and will invalidate the device
warranty.
Electrical/Optical Characteristics
Parameters
Symbol
Conditions/Notes
Min
Typ
Max
Unit
Note
Series Resistance
RS
Between IF = 20 and 80 mA
2
-
8
Ohm
Forward Voltage
VF
At laser threshold
-
1.8
V
Threshold Current
ITh
-
8
15
mA
Slope Efficiency
SE
-
0.35
-
W/A
1
Monitor Current
I
If = 40 mA, VMPD = 5 Vdc
200
-
2000
A
Monitor Dark Current
IMon,dark
VMPD = 5 Vdc
-
50
nA
Linearity
L
η
Between 30 and 80 mA
1
2
Center Emission Wavelength
λC
Iop, Top = 25C
Center WL ± 2 nm
3,4
Spectral Width
λ
-
1.0
nm
3,4
Side Mode Suppression Ratio
SMSR
-
30
40
-
dB
3,4
Notes:
1. Slope efficiency is measured in a current range between Ith + 5 mA and Ith + 65 mA.
2. Linearity is calculated by first determining slopes of five sequential pairs of points along the linear portion of the POC vs. IF curve
(
η1, η2, ... , η5) in the drive current range (30mA and 80 mA). The difference between the maximum and minimum of these slopes
divided by the slope efficiency (defined as the slope of linear regression) defines Linearity.
{
}
{
}
η
5
2
1
5
2
1
,.....,
,
,.....,
,
Min
Max
L
=
3. Spectrum is measured using an optical spectrum analyzer with a spectral resolution better than 0.1 nm.
4. Lot sample test at 20%.
