5111008-3 Product Details
Product Photo
5111008-3
T E I nternal N umber: 5 1 1 1 0 0 8 -3
Pin and Pinless Headers (AMP-LATCH)
Product Highlights:
l
Connector Type = Universal Ejection Pin Headers
l
Standard Profile
l
Number of Positions = 16
l
2.54 x 2.54 mm Centerline, Matrix
l
PCB Mount Angle = Vertical
Quick Links
Documentation & Additional Information
Product Drawings:
l
AMP-LATCH UNIVERSAL HEADER, .25 SQ POST, .100 X .100... (PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
AMP-LATCH* and IDC Header Connectors, .100 x .100 In... (PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Connector Type = Universal Ejection Pin Headers
l
Profile = Standard
l
Number of Positions = 16
l
PCB Mount Angle = Vertical
l
l
Mating Polarization Type = Center, Dual Polarizing Bar, Military
l
Mating Connector Lock = Without
l
Housing Style = 4-Sided
l
Ejection Latches = Without
l
Post Size (mm [in]) = 0.64 [.025]
l
Shrouded = Yes
l
PCB Mount Style = Through Hole (SMT Compatible)
l
Mating Polarization = With
Termination Related Features:
l
Termination Post Length (mm [in]) = 2.79 [0.110]
l
Solder Tail Contact Plating = Tin
Body Related Features:
l
Centerline, Matrix (mm [in]) = 2.54 x 2.54 [.100 x .100]
Contact Related Features:
l
Contact Mating Area Plating Material = Gold (30)
l
Contact Shape = Square
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
l
Housing Color = Red
Industry Standards:
l
RoHS/ELV Compliance = RoHS compliant, ELV compliant
l
Lead Free Solder Processes = Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C , Reflow
solder capable to 245?C , Pin-in-Paste capable to 245?C
l
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
l
Temperature Rating = High
Other:
l
Brand = AMP
