Dialight Corporation 1501 Route 34 South Farmingdale, NJ 07727 TEL: (732) 919-3119 FAX: (732) 751-5778 www.dialight.com
4
4-69
Non-Tinted, Diffused
3mm LED
Bi-Color
3TD-9664, 3TD-986x, 3TF-9484
TYPE
*3TD-9664
*3TD-9868
*3TD-9869
*3TF-9484
COLOR
Red/Green
Red/Green
Yellow/Green
Red/Green
Red/Green
-9664
Red/Green
-9868
Yellow/Green
-9869
Red/Green
-9484
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C)
Power Dissipation (mW)
75/75
100/100
60/100
75/75
Forward Current (mA)
Derating (mW/°C)
From 25°C
*Derating (mA/ °C)
From 50°C
30/30
.4*/.4*
20/30
.25*/.4*
30/30
.33*/.67*
.85/.85
Peak Current (mA)
Pulse width 10μs
100/100
30/30
80/120
100/100
Operating Temperature (°C)
-30/+85
-55/+100
-55/+100
-30/+85
Storage Temperature (°C)
-30/+100
-55/+100
-55/+100
-30/+100
Soldering Temperature
260°C, 6 seconds, 1.6 mm from case (9484 only)
260°C, 5 seconds, 1.6 mm from case (except 9484)
Red/Green
-9664
Red/Green
-9868
Yellow/Green
-9869
Red/Green
-9484
OPERATING CHARACTERISTICS
(T
A
=25°C)
Luminous Intensity (mcd)
IF=20mA *IF=10mA
Peak Wavelength (nm)
λ
Peak
Viewing Angle (2
Θ
)
Min.
Typical
4/6
8/12
2.5*/3.7*
4.7*/10*
2.5*/2.5*
4.3*/6.3*
2/2
4/4
Typical
630/560
635/565
585/565
630/560
Typical
80°
60°/60°
80°/80°
Forward Voltage (V)
Typical
2/2.1
2/2.1
2.1/2.1
2/2.1
IF=20mA
Reverse Voltage (V)
Max.
2.5/2.5
2.8/2.8
2.8/2.8
2.5/2.5
IR=100μA
Min.
5
5
5
5
REFERENCE ONLY.
* NOT A VALID PART
NUMBER. THIS SHEET IS FOR
Θ
is the off axis angle at which the luminous intensity is half the axial luminous intensity
Solder Adherence per MIL-STD-202E, Method 208C
