Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
CC)
±7V
I
OUT
Output is short circuit protected to
ground, but maximum reliability will
be maintained if I
OUT does not
exceed...
60mA
Common Mode Input Voltage
±V
CC
Differential Input Voltage
10V
Junction Temperature
+150C
Operating Temperature
40C to +85C
Storage Temperature Range
65C to +150C
Lead Solder Duration (+300C)
10 sec
ESD rating (human body model)
2000V
Operating Ratings
Thermal Resistance (SOIC)
θ
JC
60C/W
θ
JA
140C/W
Electrical Characteristics
A
V = +6, VCC = ±5V, Rf = 1000,Cp = 100pF; unless specified
Symbol
Parameter
Conditions
Typ
Max/Min Ratings (Note 2)
Units
Ambient Temperature
CLC505AJ
+25C
40C
+25C
+85C
Frequency Domain Response
SSBW
-3dB Bandwidth
V
OUT <2VPP
150
>115
>100
MHz
LSBW
-3dB Large Signal
V
OUT <5VPP
135
>95
>80
MHz
Gain Flatness
V
OUT < 2VPP
GFPL
Peaking
<25/20/10MHz (Note 7)
0
<0.4
<0.3
<0.4
dB
GFPH
Peaking
>25/20/10MHz (Note 7)
0
<0.6
<0.5
<0.6
dB
GFR
Rolloff
<50/40/20MHz (Note 7)
0.2
<1.0
<1.3
dB
LPD
Linear Phase Deviation
DC to 50/40/20MHz (Note 7)
0.6
<1.0
<1.2
deg
Time Domain Response
TRS
Rise and Fall Time
2V Step
2.3
<3.0
<3.5
ns
TRL
5V Step
2.6
<3.7
<4.4
ns
TSP
Settling time to 0.1/0.05/0.05%
(Note 7)
2V Step
12
<16
ns
OS
Overshoot
2V Step
5
<15
<12
<15
%
SR
Slew Rate (A
V +2)
1700
>1000
>1200
V/s
Distortion And Noise Response
HD2
2nd Harmonic Distortion
2V
PP,20/10/5MHz (Note 7)
50
<40
<45
dBc
HD3
3rd Harmonic Distortion
2V
PP,20/10/5MHz (Note 7)
65
<55
dBc
Equivalent Input Noise
SNF
Noise Floor
>1MHz
156
<154
<153
dBm
(1Hz)
INV
Integrated Noise
1MHz to 200/200/100MHz
(Note 7)
50
<65
<70
V
DG
Differential Gain (Note 6)
0.04
-
%
DP
Differential Phase (Note 6)
0.06
-
deg
Static, DC Performance
VIO
Input Offset Voltage (Note 3)
2
<±12.8
<±8.0
<±14
mV
DVIO
Average Temperature
Coefficient
30
<±50
-
<±50
V/C
IBN
Input Bias Current (Note 3)
Non Inverting
8
<±36
<±18
A
DIBN
Average Temperature
Coefficient
80
<±225
-
<±100
nA/C
IBI
Input Bias Current (Note 3)
Inverting
10
<±60
<±38
<±40
A
DIBI
Average Temperature
Coefficient
80
<±275
-
<±125
nA/C
PSRR
Power Supply Rejection Ratio
50
>45
>48
>45
dB
CMRR
Common Mode Rejection Ratio
50
>45
>48
>45
dB
CLC505
www.national.com
2
