- 您現在的位置：買賣IC網 > PDF目錄2131 > 6-1542004-6 (TE Connectivity)25MM HS ASSY ULTEM CL PDF資料下載
參數資料
| 型號： | 6-1542004-6 |
| 廠商： | TE Connectivity |
| 文件頁數： | 1/1頁 |
| 文件大?。?/td> | 0K |
| 描述： | 25MM HS ASSY ULTEM CL |
| RoHS指令信息： | 6-1542004-6 Statement of Compliance |
| 標準包裝： | 750 |
| 系列： | * |
| 其它名稱： | HTS779-U |
3-FIN HS:
1
4-LEG CLIP AIZE: 25mm
2
1.000 DIA.
0.442 HT.
SECTION B-B
5/8 - 27 UNS 2A
THREAD
.998
.442
A
±.005
.245
LIP LEG
.312
1.000
1.069
MAX
.070
±.020
.983
.115±.005
B
MATERIAL:
FINISH:
SEE NOTE
B.PETROCELLI
04/07/04
A
B
C
D
7
8
A
B
C
D
1
2
3
A
SHEET:
1 OF 1
TNIRD ANGLE
4
ANY PURPOSES EXCEPT AS AUTHORIZED
IN WRITING BY AN AUTHORIZED OFFICIAL
5
ELECTRONICS. NOT TO BE DISCLOSED
ON DEMAND, ON COMPLETION OF ORDERS
6
.
.XXX
(HTS779-U)
7
8
TO OTHERS. REPRODUCED OR USED FOR
C-6-1542004-6
DWG. NO.
UNLESS OTHERWISE
.XX
.
DATE
DRAWN BY:
ENGINEER:
E.TAO
03/05/04
TITLE:
SIZE:
2:1
REV:
A1
SCALE:
OF TYCO. MUST BE RETURNED TO TYCO
TOLERANCES ARE:
.
.XXXX
PROJECTION
PART NO:
25mm HS ASS'Y
ANGLES
SPECIFIED
6-1542004-6
DIMENSONS ARE IN:
INCHES
FILENAME
PROJECT
SYSTEM
CONFIDENTIAL PROPERTY OF TYCO
OR OTHER PURPOSES FOR WHICH LENT.
DO
NOT
S
C
A
LE
DATE
1. MATERIAL:
HEAT SINK: ALUM. (BLACK ANODIZE)
CLIP:
BLACK PEI (UL94-VO)
2. BEFORE THE HEATSINK APPLICATION, THE USER
SHOULD IDENTIFY THE SPECIFICATION OF MAXIMUM
LOAD ON THE BGA PACKAGE.
HEATSINK TORQUE SPECIFICATIONS CONVERTED TO FORCE.
BARE DIE PACKAGE:
1.5 POUND-FORCE INCH TORQUE = 8.5 POUND-FORCE
(0.17 NEWTON TORQUE = 37.81 NEWTON)
2.0 POUND-FORCE INCH TORQUE = 11.4 POUND-FORCE
(0.23 NEWTON METER TORQUE = 50.71NEWTON)
FULL SIZE LID PACKAGE:
1.5 POUND-FORCE INCH TORQUE = 8.3 POUND-FORCE
(0.17 NEWTON TORQUE = 36.92NEWTON)
2.0 POUND-FORCE INCH TORQUE = 11.1 POUND-FORCE
(0.23 NEWTON METER TORQUE = 49.38NEWTON)
3. REMOVE CLIP WITH REMOVAL TOOL P/N: 1542616-1.
4. RoHS COMPLIANT AND CERTIFIED.
DETAIL A
SCALE = 6X
.016±.002
REVISION(S)
LTR
DESCRIPTION
INIT
APP'D
O
ECN: 0S60- 0081- 04
E.T 03/31/04
B.P 04/07/04
A
ECR- 06- 011657
E.T 6/2/06
V.K 6/2/06
A1
ECR- 06- 023572
E.T 10/13/06
V.K 10/13/06
ITEM
DESCRIPTION
QTY
1
MOUNTING CLIP
1
2HEAT SINK
1
---
-----------------
----
CUST OMER DRAWING
SPECIFICATIONS ARE SUBJECT TO CHANGE W ITHOUT NOTICE
Power
° C/W @
Ambient
° C/W @
200 LFM
° C/W @
400 LFM
° C/W @
600 LFM
5 Watts
--
10 W atts
11.56
6.71
4.94
4.02
15 W atts
--------
