Harness Sectioning Connectors
Coupling connectors
DCS-2/ 4.8 mm
48 way sealed connector system
48 position female housing for
1.5 and 5.8 mm terminals
Locking cam secured in pre-fixed
position
Connector position assurance
(CPA) optional possible
48 position male housing for 1.5
and 4.8 mm terminals
Protection cover for male terminals
Interface sealing possible on the
male housing
Single wire sealing possible
Cable exit left and right possible
Cable protection cover useable for
male and female side
Features
5.51
Performance characteristics
Temperature range:
from -40°C to +120°C
Contact retention force:
> 55 N for DCS-2 1.5 mm
Contact insertion force:
< 10 N for DCS-2 1.5 mm
Connector mating force: Consult us
Sealing protection:
IPX 9K
Construction
Housing material:
PBT
Mat seal:
Silicone
Tooling
Terminal removal tool:
Consult us
Connector compatibility
Useable terminals:
- DCS-2 1.5 mm female terminals
- 4.8 mm female terminals
Matable with:
- DCS-2 1.5 mm male terminals
- 4.8 mm male terminals
Part Numbers
No. of pos.
Terminal size
Type
Version
Colour
6 043 21 01
48
46 x 1.5 mm + 2 x 4.8 mm
Female housing
Cable exit right
Black
6 043 21 11
48
46 x 1.5 mm + 2 x 4.8 mm
Female housing
Cable exit left
Black
6 053 05 01
48
46 x 1.5 mm + 2 x 4.8 mm
Male housing
Cable exit right
Black
6 053 05 11
48
46 x 1.5 mm + 2 x 4.8 mm
Male housing
Cable exit left
Black
6 053 18 01
48
46 x 1.5 mm + 2 x 4.8 mm
Male housing
Cable exit right
Black
6 900 37 00
Mat-Seal
Nature
6 039 01 01
Protection cover for male terminals
Black
6 099 46 01
Cable protection cover
for corrugated tube
Black
6 099 60 01
Cable protection cover
Black
Rev
0
6/0
4
