Pomona
All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (,51 mm), .xxx = ± .005” (,127 mm).
All specifications are to the latest revisions. Specifications are subject to change without notice.
Registered trademarks are the property of their respective companies. Made in USA
6/9/99
PomonaACCESS 90774 (800) 444-6785 or (425) 446-6010
SY/EH/LS
More drawings available at www.pomonaelectronics.com
C:\Laura Goldberg\FlukeDataSheet\d6172_2_01.doc
Page 2 of
2
Model 6172
Test Companion Kit For
Fluke 80 Series DMM’s
Sales: 800-490-2361 Fax: 888-403-3360
Technical Assistance: 800-241-2060
FEATURES:
Ideal for use with Fluke 80 Series Digital Multimeters
Test Accessories (except spade lugs) comply to IEC 1010-2-031, which is the International Safety Standard
for test accessories
Includes Cordura shoulder pack carrying case
MATERIALS:
Model 5898: Replacement Test Lead Kits - Inner Insulation – Polypropylene, Fire Retardant, Color: One Black, One
Red Tip: Brass Wire: 18 AWG, 65 x 36 Tinned Copper Strand, Silicone Insulation, Length: 48” (122cm), O.D. .144”
(3,66mm) Banana Plug: Body – Brass, Nickel Plated - Spring – Beryllium Copper, Nickel Plated - Insulation – PVC,
Color: One Black, One Red, RATINGS: IEC 1010-2-031, Category III, P2 Compliant, 1,000 VRMS/DC, 10
Amperes
Model 5907A:
Test Lead Straight to Right Angle: Banana Spring: Nickel plated Beryllium Copper, Insulation–Polypropylene, fire
retardant, UL94 V-2, Wire: 48" silicone 18" AWG, Color: One Black, One Red, RATINGS: 1000 VRMS, 10
Amperes
Model 5916A: Medium Alligator Clip: Body–Steel, Nickel plated, Insulation–Polypropylene, fire retardant, UL94 V-2,
Color: One Black, One Red, RATINGS: 300 VRMS, 5 Amperes
Model 6282: Modular Probe w/Banana Plug Tip: Probe Body: Polypropylene – Fire Retardant – UL94V-HB rated,
Plug Tip: Body – Brass, Nickel Plated, Spring – Beryllium Copper, Nickel Plated, 4mm Safety Jack: Brass, Nickel
Plated, RATINGS: IEC 1010-2-031, Category III, P2 Compliant, Voltage: 1000 VRMS/DC Max., Current: 10
Amperes Max.
Model 6203: Spade Lug: Brass, nickel plated, Insulation - Nylon 6, fire retardant, UL94 V-O, Spade - Nickel plated
copper, Color: One Black, One Red, RATINGS: 1000 VRMS, 15 Amperes
Model 5910A: Maxigrabber set with Pincer Tip - RATINGS: 1000 VRMS, 10 Amperes, CAT III, P2
Model 5911A: Maxigrabber set with Hook Tip - RATINGS: 1000 VRMS, 10 Amperes, CAT III, P2
ORDERING INFORMATION: Model 6172 (Kit includes items from above)
Replacement P/N’s: Model 5898: Replacement Test Lead Kits, Model 5907A: Test Lead Straight to Right Angle,
Model 5916A: Medium Alligator Clip, Model 6282: Test Probe with Stainless Steel Tip, Model 6203:
Spade Lug, Model 5910A: Maxigrabber set with Pincer Tip, Model 5911A: Maxigrabber set with Hook Tip
