December 1990
2
Philips Semiconductors
Product specification
Hex high-to-low level shifter
74HC4050
FEATURES
Output capability: standard
I
CC
category: SSI
GENERAL DESCRIPTION
The 74HC4050 is a high-speed Si-gate CMOS device and
is pin compatible with the “4050” of the “4000B” series. It
is specified in compliance with JEDEC standard no. 7A.
The 74HC4050 provides six non-inverting buffers with a
modified input protection structure, which has no diode
connected to V
CC
. Input voltages of up to 15 V may
therefore be used. This feature enables the non-inverting
buffers to be used as logic level translators, which will
convert high level logic to low level logic, while operating
from a low voltage power supply. For example 15 V logic
(“4000B series”) can be converted down to 2 V logic.
The actual input switch level remains related to the V
CC
and is the same as mentioned in the family characteristics.
APPLICATIONS
Converting 15 V logic (“4000B” series) down to 2 V logic.
QUICK REFERENCE DATA
GND = 0 V; T
amb
= 25
°
C; t
r
= t
f
= 6 ns
Notes
1.
C
PD
is used to determine the dynamic power dissipation (P
D
in
μ
W):
P
D
= C
PD
×
V
CC2
×
f
i
+
∑
(C
L
×
V
CC2
×
f
o
) where:
f
i
= input frequency in MHz
f
o
= output frequency in MHz
C
L
= output load capacitance in pF
V
CC
= supply voltage in V
∑
(C
L
×
V
CC2
×
f
o
) = sum of outputs
ORDERING INFORMATION
See
“74HC/HCT/HCU/HCMOS Logic Package Information”
.
SYMBOL
PARAMETER
CONDITIONS
TYPICAL
UNIT
HC
t
PHL
/ t
PLH
C
I
C
PD
propagation delay nA to nY
input capacitance
power dissipation capacitance per buffer
C
L
= 15 pF; V
CC
= 5 V
7
3.5
14
ns
pF
pF
note 1
