1999 Apr 15
3
Philips Semiconductors
Product specication
NPN medium frequency transistor
BFS20
THERMAL CHARACTERISTICS
Note
1. Transistor mounted on an FR4 printed-circuit board.
CHARACTERISTICS
Tj =25 °C unless otherwise specied.
SYMBOL
PARAMETER
CONDITIONS
VALUE
UNIT
Rth j-a
thermal resistance from junction to ambient
note 1
500
K/W
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
ICBO
collector cut-off current
IE = 0; VCB =20V
100
nA
IE = 0; VCB = 20 V; Tj = 100 °C
10
A
IEBO
emitter cut-off current
IC = 0; VEB =4V
100
nA
hFE
DC current gain
IC = 7 mA; VCE = 10 V
40
85
VBE
base-emitter voltage
IC = 7 mA; VCE =10V
740
900
mV
Cc
collector capacitance
IE =ie = 0; VCB =10V; f=1MHz
1
pF
Cre
feedback capacitance
IC = 0; VCB =10V; f=1MHz
350
fF
fT
transition frequency
IC = 5 mA; VCE = 10 V; f = 100 MHz
275
450
MHz
