參數資料
| 型號： | 935165940112 |
| 廠商： | NXP SEMICONDUCTORS |
| 元件分類： | 畫面疊加 |
| 英文描述： | ON-SCREEN DISPLAY IC, PDSO24 |
| 封裝： | PLASTIC, SOT-137-1, SO-24 |
| 文件頁數： | 12/66頁 |
| 文件大小： | 445K |
| 代理商： | 935165940112 |
