參數資料
型號： 94152-086
元件分類： 電信和以太網連接器
英文描述： 8 CONTACT(S), FEMALE, STRAIGHT TELECOM AND DATACOM CONNECTOR, SOLDER, JACK
文件頁數： 2/2頁
文件大?。?/td> 115K
代理商： 94152-086
Technical Data
Materials
Housing ......High temperature thermoplastic UL 94 V-0
or Thermoplastic resin UL 94 V-0
Contact........................Copper alloy with gold or GXT
(palladium-nickel alloy) plating
Shield..........................................Tin-plated copper alloy
Electrical Performance
Attenuation @ 100 MHz ................................0.13 dB max.
Return loss @ 100 MHz ......................................19 dB min.
DWV..............................1000 V AC (RMS) signal to signal,
1500 V AC (RMS) signal to shield
Near end crosstalk ............Characterized up to 100MHz
ref. EIA/TIA 568
Mating Data
RJ45 plug cable, shielded and unshielded
Options
GXT plating or gold plating in the contact area
PCB Layout (see below)
Specifications
FCC, Part 68 Subpart F
EIA/TIA 568
IEC 603.7
Approvals and Certifications
UL and CSA
Packaging
Trays or tubes
Internet: www.fciconnect.com
s
Americas Tel.: (800) 237-2374; 717-938-7200
s
Europe Tel.: 31-73-6206-911
s
Asia/Pacific Tel.: 65-549-6666
950528-017 12/99
FCI connects the world
For options or additional product information, call your local FCI representative.
Recommended PC Board Layout
P/N 52405-XXX
Recommended PC Board Layout
P/N
Peg Style
Panel
Type of
Stop
Plastic
52377-XXX
Snap
No
High Temp
91133-XXX
Diamond
Yes
Standard
91139-XXX
Diamond
No
Standard
94152-XXX
Snap
Yes
Standard
