| 型號： | 950405AFLFT |
| 廠商： | INTEGRATED DEVICE TECHNOLOGY INC |
| 元件分類： | 時鐘產生/分配 |
| 英文描述： | 300 MHz, PROC SPECIFIC CLOCK GENERATOR, PDSO48 |
| 封裝： | 0.300 INCH, GREEN, MO-118, SSOP-48 |
| 文件頁數： | 9/18頁 |
| 文件大?。?/td> | 219K |
| 代理商： | 950405AFLFT |
Global Sites
Search Entire Site
Document Search | Package Search | Parametric Search | Cross Reference Search | Green & RoHS | Calculators | Thermal Data | Reliability & Quality | Military
950405 (Desktop Chipsets)
Description
AMD K8 System Clock with AMD, VIA or ALI Chipset
Market Group
PC CLOCK
Additional Info
The ICS950405 is a main system clock solution for desktop designs using the AMD K8 CPU. It provides all necessary clock signals for
Clawhammer and Sledgehammer with AMD, VIA or ALI systems. The ICS950405 is part of a whole new line of ICS clock generators and
buffers called TCH (Timing Control Hub). This part incorporates ICS's newest clock technology which offers more robust features and
functionality. Employing the use of a serially programmable I2C interface, this device can adjust the output clocks by configuring the frequency
setting, the output divider ratios, selecting the ideal spread percentage, the output skew, the output strength, and enabling/disabling each
individual output clock. M/N control can configure output frequency with resolution up to 0.1MHz increment. Programmable output frequency.
Programmable output divider ratios. Programmable output rise/fall time. Programmable output skew. Programmable spread percentage
for EMI control. Watchdog timer technology and RESET# output to reset system if system malfunctions. Programmable watch dog safe
frequency. Support I2C Index read/write and block read/write operations. Uses external 14.318MHz crystal. Supports Hyper Transport
Technology (HTTCLK).
