參數資料
| 型號： | 952703BF |
| 廠商： | INTEGRATED DEVICE TECHNOLOGY INC |
| 元件分類： | 時鐘產生/分配 |
| 英文描述： | 217.9 MHz, PROC SPECIFIC CLOCK GENERATOR, PDSO48 |
| 封裝： | GREEN, MO-118, SSOP-48 |
| 文件頁數： | 3/19頁 |
| 文件大?。?/td> | 264K |
| 代理商： | 952703BF |
11
Integrated
Circuit
Systems, Inc.
ICS952703
Preliminary Product Preview
0813B—05/17/05
Electrical Characteristics - CPUCLKT/C
TA = 0 - 70°C; VDD=3.3V +/-5%; CL = 10-20 pF (unless otherwise specified)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX UNITS
Current Source
Output Impedance
Zo
1
VO = Vx
3000
Output High Voltage
VOH3
IOH = -1 mA
2.4
V
Output Low Voltage
VOL3
IOL = 1 mA
0.4
Rise Time
tr3
VOL = 0.175V, VOH = 0.525V
175
700
ps
Fall Time
tf3
VOH = 0.175V VOL = 0.525V
175
700
ps
Duty Cycle
dt3
VT = 50%
45
55
%
Skew
tsk3
VT = 50%
100
ps
Jitter, Cycle to cycle
tjcyc-cyc
1
VT = 50%
150
ps
Electrical Characteristics - PCICLK
TA = 0 - 70°C; VDD = 3.3 V,+/-5%; CL = 30 pF
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX UNITS
Output High Voltage
VOH1
IOH = -18 mA
2.1
V
Output Low Voltage
VOL1
IOL = 9.4 mA
0.4
V
Output High Current
IOH1
VOH = 2.0 V
-22
mA
Output Low Current
IOL1
VOL = 0.8 V
16
57
mA
Rise Time
1
tr1
VOL = 0.4 V, VOH = 2.4 V
2
ns
Fall Time
1
tf1
VOH = 2.4 V, VOL = 0.4 V
2
ns
Duty Cycle
1
dt1
VT = 1.5 V
45
55
%
Skew
1
tsk1
VT = 1.5 V
500
ps
tjcyc-cyc
1
VT = 1.5 V
500
ps
tjabs1
VT = 1.5 V
500
ps
1Guaranteed by design, not 100% tested in production.
Jitter
