ACM2004E SERIES LCD MODULE
AZ DISPLAYS, INC.
4/24/02 1
1.0 MECHANICAL SPECS
1. Overall Module Size
182.0mm(W) x 90.0mm(H) x max 13.0mm(D) for LED backlight
version
182.0mm(W) x 90.0mm(H) x max 9.50mm(D) for reflective
version
2. Dot Size
1.10mm(W) x 1.50mm(H)
3. Dot Pitch
1.20mm(W) x 1.60mm(H)
4. Duty
1/16
5. Controller IC
ST7066
6. LC Fluid
TN, STN
7. Polarizer
Reflective, Transflective, Transmissive
8. Viewing Angle
Bottom, Top
9. Backlight
Side LED
10. Temperature Range
Standard(0”C ~ 50”C), Wide(-20”C ~ 70”C)
2.0 ABSOLUTE MAXIMUM RATINGS
Item
Symbol
Min
Typ
Max
Unit
Operating temperature (Standard)
Top
0
-
50
”C
Storage temperature (Standard)
Tst
-10
-
60
”C
Operating temperature (Wide temperature)
Top
-20
-
70
”C
Storage temperature (Wide temperature)
Tst
-30
-
80
”C
Input voltage
Vin
Vss
Vdd
V
Supply voltage for logic
Vdd- Vss
2.7
-
5.5
V
Supply voltage for LCD drive
Vdd- Vo
3.0
4.6
6.5
V
