30430 Rev. 3.43 October 2004
AMD Athlon 64 Processor Power and Thermal Data Sheet
Chapter 3
AMD Sempron Desktop Processor
23
Table 20 AMD Sempron Processor Thermal/Power Specifications
Parameter/OPN
Model Number
CPUID 8000_0001h EAX [31:0]
7
FID/VID Status MaxVID Field
8
FID/VID Status MaxFID Field
8
FID/VID Status StartVID Field
8
FID/VID Status StartFID Field
8
L2 Cache Size
T
CASE
Max
10
T
CONTROL
Max
11
Max P-State
VID_VDD
IDD Max
Thermal Design Power
1
Thermal Resistance (case-to-ambient)
9
Intermediate P-State #1
VID_VDD
IDD Max
Thermal Design Power
1
Intermediate P-State #2
VID_VDD
IDD Max
Thermal Design Power
1
Intermediate P-State #3
VID_VDD
IDD Max
Thermal Design Power
1
Min P-State
VID_VDD
IDD Max
Thermal Design Power
1
Halt/Stop Grant at Max P-State
2
IDDC1 Max
I/O Power
5
Halt/Stop Grant at Min P-State
3
IDDC1 Max
I/O Power
5
S3
4
I/O Power
4,6
Notes:
1.
Thermal Design Power (TDP) is measured under the conditions of T
CASE
Max, IDD Max, and VDD=VID_VDD,
and include all power dissipated on-die from VDD, VDDIO, VLDT, VTT, and VDDA.
2.
Assumes t
CASE
max, VDD, clock divider set to 32.
3.
Assumes 50
°
C, VDD nom, clock divider set to 32.
4.
Assumes 35
°
C, VDD, VDDA, and VLDT supplies are off, VDDIO and VTT are powered, memory in self-refresh
mode and DDR SDRAM interface tri-stated except CKE pins.
5.
Thermal Design Power for VDDIO, VTT, VLDT, and VDDA power planes only.
6.
Thermal Design Power for VDDIO and VTT power planes only.
SDA3100AIP3AX
3100+
00000FC0h
04h
0Ah
06h
0Ah
256 KB
70°C
70°C
1800 MHz
1.40 V
42.7 A
62 W
0.45
°
C/W
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1000 MHz
1.1 V
16.2 A
20 W
30.0 A
2.2 W
7.0 A
2.2 W
160 mW
