5
Absolute Maximum Ratings [1,2]
Parameter
Symbol
Min.
Max.
Unit
Reference
Storage Temperature
(non-operating)
TS
–40
100
°C
1
Case Temperature (operating)
TC
90
°C
1, 2, 4
Supply Voltage
VCC
–0.5
4.6
V
1, 2
Data/Control Signal Input Voltage
VI
–0.5
VCC + 0.5
V
1
Transmitter Differential Data Input
Voltage
|VD|
2
V
1, 3
Output Current (dc)
ID
25
mA
1
Relative Humidity (non-condensing) RH
5
95
%
1
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Case Temperature
TC
0
40
80
°C
2, Figs. 3, 4
Supply Voltage
VCC
3.135
3.3
3.465
V
Figs. 5, 6,
12
Signaling Rate per Channel
1
2.5
Gbd
3
Data Input Differential
Peak-to-Peak Voltage Swing
DVDINP-P
175
1400
mVP-P
4, Figs. 7, 8
Control Input Voltage High
VIH
2.0
VCC
V
Control Input Voltage Low
VIL
VEE
0.8
V
Power Supply Noise for
Transmitter and Receiver
NP
200
mVP-P
5, Figs. 5, 6
Transmitter/Receiver Data
I/O Coupling Capacitors
CAC
0.1
mF
Fig. 7
Receiver Differential Data
Output Load
RDL
100
W
Fig. 7
Notes:
1. Absolute Maximum Ratings are those values beyond which damage to the device may occur. See Reliability Data Sheet for specific reliability
performance.
2. Between Absolute Maximum Ratings and the Recommended Operating Conditions functional performance is not intended, device reliability
is not implied, and damage to the device may occur over an extended period of time.
3. This is the maximum voltage that can be applied across the Transmitter Differential Data Inputs without damaging the input circuit.
4. Case Temperature is measured as indicated in Figure 3.
Recommended Operating Conditions [1]
Notes:
1. Recommended Operating Conditions are those values outside of which functional performance is not intended, device reliability is not im-
plied, and damage to the device may occur over an extended period of time. See Reliability Data Sheet for specific reliability performance.
2. Case Temperature is measured as indicated in Figure 3. A +55 °C, 1 m/s, parallel to the printed circuit board, air flow at the module or equiva-
lent cooling is required. See Figure 4.
3. The receiver has a lower cut off frequency near 100 kHz.
4. Data inputs are CML compatible. Coupling capacitors are required to block DC. DVDINP-P = DVDINH – DVDINL, where DVDINH = High State Differ-
ential Data Input Voltage and DVDINL = Low State Differential Data Input Voltage.
5. Power Supply Noise is defined for the supply, VCC, over the frequency range from 500 Hz to 2500 MHz, with the recommended power supply
filter in place, at the supply side of the recommended filter. See Figures 5 and 6 for recommended power supply filters.
