12
Optical Parameters
Absolute Maximum Ratings
Absolute maximum ratings are those values beyond which functional performance is not intended, device reliability is not
implied, and damage to the device may occur.
Notes:
1. MSA gives max current at 300 mA.
2. MSA filter is required on host board 10 Hz to 2 MHz.
3. LVTTL, External 4.7-10 K
pull up resistor required on host board to voltage less than Vcc + 0.3 V.
4. Internally ac coupled and terminated (100
differential).
5. Internally ac coupled and load termination located at the user SERDES.
6.
Minimum input to MOD-DEF1,2 is 0.7*VCC
Transceiver Electrical Characteristics for multirate operations at Fast Ethernet (125 Mbit/s) and OC-3 (155 Mbit/s) *6
Recommended Multirate Operating Conditions
Typical operating conditions are those values for which functional performance and device reliability is implied.
Parameter
Symbol
Minimum
Maximum
Unit
Notes
Storage Temperature (non-operating)
TS
-40
+85
° C
Relative Humidity
RH
0
85
%
Supply Voltage
VCC
-0.5
3.63
V
Input Voltage on any Pin
VI
-0.5
VCC
V
Receiver Optical Input
PINABS
0
dBm
Parameter
Symbol
Minimum
Typical
Maximum
Unit
Notes
Case Operating Temperature
AFCT-576xNLZ/NPZ
AFCT-576xANLZ/ANPZ
TC
-10
-40
+85
° C
Supply Voltage
VCC
3.1
3.3
3.5
V
Parameter
Symbol
Minimum
Typical
Maximum
Unit
Notes
Module supply current
ICCT
250
mA
1
Power Dissipation
PDISS
875
mW
AC Electrical Characteristics
Power Supply Noise Rejection
PSNR
100
mV
2
In-rush Current
30
mA
DC Electrical Characteristics
Signal Outputs:
Transmit Fault (TX_FAULT)
Loss of Signal (LOS)
VOH
2.0
3.5
V
3
VOL
00.8
V
Signal Inputs:
Transmitter Disable (TX_DISABLE)
MOD-DEF1, 2
VIH
2.0
3.5
V
6
VIL
00.8
V
Data Input:
Transmitter Single Ended Input Voltage (TD±)
VI
250
1200
mV
4
Data Ouput:
Receiver Single Ended Output Voltage (RD±)
VO
250
1000
mV
5
