參數資料
| 型號： | AFCT-5962NLZ |
| 元件分類： | 光收發 |
| 英文描述： | FIBER OPTIC TRANSCEIVER, 1261-1580nm, 155Mbps(Tx), 155Mbps(Rx), BOARD/PANEL MOUNT, DIP, LC CONNECTOR |
| 封裝： | ROHS COMPLIANT, DIP-20 |
| 文件頁數： | 7/16頁 |
| 文件大?。?/td> | 514K |
| 代理商： | AFCT-5962NLZ |
15
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Output Optical Power 9 m SMF
POUT
-15
-8
dBm
1
Center Wavelength
lC
1261
1360
nm
Spectral Width - rms
s
7.7
nm rms
2
Optical Rise Time
tr
2ns
3
Optical Fall Time
tf
2ns
3
Extinction Ratio
ER
8.2
dB
Output Optical Eye
Compliant with eye mask Telcordia GR-253 CORE and ITU-T G.957
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Output Optical Power 9 m SMF
POUT
-5
0
dBm
1
Center Wavelength
lC
1270
1360
nm
Spectral Width - rms
s
3nm rms
2
Optical Rise Time
tr
2ns
3
Optical Fall Time
tf
2ns
3
Extinction Ratio
ER
10
dB
Output Optical Eye
Compliant with eye mask Telcordia GR-253-CORE and ITU-T G.957
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Receiver Sensitivity AFCT-5962TLZ/TGZ/ATLZ/ATGZ
Receiver Sensitivity AFCT-5962NLZ/NGZ
PIN MIN
-38
-31
-34
dBm avg.
4
Receiver Overload
PIN MAX
-8
0
dBm avg.
4
Input Operating Wavelength
l
1261
1580
nm
Signal Detect - Asserted
PA
-39.8
-34
dBm avg.
Signal Detect - Deasserted
PD
-45
-41.9
dBm avg.
Signal Detect - Hysteresis
PA - PD
0.5
2
4
dB
Notes:
1.
The output power is coupled into a 1 m single-mode fiber. Minimum output optical level is at end of life.
2.
The relationship between FWHM and RMS values for spectral width can be derived from the assumption of a Gaussian shaped spectrum which
results in RMS = FWHM/2.35.
3.
These are unfiltered 10-90% values.
4.
PIN represents the typical optical input sensitivity of the receiver. Sensitivity (PINMIN) and saturation (P) levels for a 223-1 PRBS with 72 ones
and 72 zeros inserted. Over the range the receiver is guaranteed to provide output data with a Bit Error Rate better than or equal to 1 x 10-10.
Receiver Optical Characteristics
AFCT-5962TLZ/TGZ: TA = 0 °C to +70 °C, VCC = 3.1 V to 3.5 V)
AFCT-5962NLZ/NGZ: TA = -5 °C to +70 °C, VCC = 3.1 V to 3.5 V)
AFCT-5962ATLZ/ATGZ: TA = -40 °C to +85 °C, VCC = 3.1 V to 3.5 V)
Transmitter Optical Characteristics
AFCT-5962TLZ/TGZ: TA = 0 °C to +70 °C, VCC = 3.1 V to 3.5 V)
AFCT-5962ATLZ/ATGZ: TA = -40 °C to +85 °C, VCC = 3.1 V to 3.5 V)
Transmitter Optical Characteristics
AFCT-5962NLZ/NGZ: TA = -5 °C to +70 °C, VCC = 3.1 V to 3.5 V)
