RIA electronic, Inc. 430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
fax 732-389-9066 www.riaelectronic.com
G-2
G
Subject to technical changes and printing errors.
Electrical Data
Voltage
600 V
centerline
8
10
Current (A)
20
30
Wire range (AWG)
12 - 22
10 - 22
Screw torque (lbs.-in)
3.5
4.4
Wire strip length (mm)
5.3
7.3
Mechanical Data
Housing
UL 94V-2
Working Temperature 105 °C
Color
natural
Terminal
brass metal alloy, tin plated
centerline
8
10
Screw
M2.6
M3
zinc plated, yellow chromed
Wire protector
stainless spring steel
Pole sizes
1 to 12
Dimensions (mm)
mm to inch
1 inch = 25.4 mm
1 mm
= .040 inches
A T W
Flat base
without wire
protection
01
ATW01 centerline 8 mm
Part No. ATW01 D
09
01 02 03 04 05 06 07 08
09 10 11 12
Complete the part number
by adding the pole size.
Part Numbers
A T W
Flat base
with wire protection
02
Additional Centerline
ATW 01
ATW 02
ATW01 centerline 10 mm
Part No. ATW01 9
09
01 02 03 04 05 06 07 08
09 10 11 12
ATW02 centerline 8 mm
Part No. ATW02 D
09
01 02 03 04 05 06 07 08
09 10 11 12
Complete the part number
by adding the pole size.
ATW02 centerline 10 mm
Part No. ATW02 9
09
01 02 03 04 05 06 07 08
09 10 11 12
Electrical Data
Voltage
600 V
centerline
8
10
Current (A)
20
30
Wire range (AWG)
12 - 22
10 - 22
Screw torque (lbs.-in)
3.5
4.4
Wire strip length (mm)
5.3
7.3
Mechanical Data
Housing
UL 94V-2
Working Temperature 105 °C
Color
natural
Terminal
brass metal alloy, tin plated
centerline
8
10
Screw
M2.6
M3
zinc plated, yellow chromed
Pole sizes
1 to 12
centerline
AB
C
D
E
F
8
95.8
16.3
13.3
8.0
2.9
2.8±0.1
10
117.0
20.2
15.8
10.0
3.6
3.2±0.1
centerline
AB
C
D
E
F
8
95.8
16.3
13.3
8.0
2.9
2.8±0.1
10
117.0
20.2
15.8
10.0
3.6
3.2±0.1
