Skyworks Solutions, Inc. Phone [781] 376-3000 Fax [781] 376-3100 sales@skyworksinc.com www.skyworksinc.com
July 19, 2007 Skyworks Proprietary Information Products and Product Information are Subject to Change Without Notice. 200221 Rev. B
DATA SHEET AV102-12, AV102-12LF
4
Characteristic
Value
RF input power
.5 W CW, 4 W @ 12.5%
duty cycle
Control current
50 mA each diode
Operating temperature
-40 °C to +85 °C
Storage temperature
-65 °C to +150 °C
Maximum reverse diode voltage
-10 V
Electrostatic discharge
125 V
Absolute Maximum Ratings
Recommended Board Layout
0.1630
0.0200 Dia.
Via 4 Places
0.0190 Typ.
0.0555 Typ.
SOIC-8
0.049
(1.24 mm)
0.016
(0.41 mm)
0.016 Max.
(0.41 mm) x
45 Chamfer
Pin 1
0.197 (5.00 mm)
0.189 (4.80 mm)
0.068
(1.73 mm) Max.
0.010 (0.25 mm)
0.004 (0.10 mm)
0.010 (0.25 mm)
0.007 (0.17 mm)
0.158 (4.00 mm)
0.150 (3.80 mm)
8
Max.
0.020 (0.51 mm) Max.
0.244 (6.20 mm)
0.228 (5.80 mm)
0.050 (1.27 mm) BSC
Pin 8
Pin 1
Indicator
1
2
3
4
Control
Current
GND
220 pF
RF In
GND
680
8
7
6
5
GND
220 pF
100 nH
RF Out
Control
Current
GND
VCONTROL
Pin Out
Material is 10 mil FR4.
Performance is guaranteed only under the conditions listed in the specifications table and is
not guaranteed under the full range(s) described by the Absolute Maximum specifications.
Exceeding any of the absolute maximum/minimum specifications may result in permanent
damage to the device and will void the warranty.
CAUTION: Although this device is designed to be as robust as
possible, ESD (Electrostatic Discharge) can damage
this device. This device must be protected at all times
from ESD. Static charges may easily produce poten-
tials of several kilovolts on the human body or
equipment, which can discharge without detection.
Industry-standard ESD precautions must be employed
at all times.
