Philips Semiconductors
Product specification
PowerMOS transistor
Logic level FET
BUK555-60H
GENERAL DESCRIPTION
QUICK REFERENCE DATA
N-channel enhancement mode logic
level field-effect power transistor in
a plastic envelope.
The device is intended for use in
Automotive applications, Switched
Mode Power Supplies (SMPS),
motor control, welding, DC/DC and
AC/DC converters, and in general
purpose switching applications.
SYMBOL
PARAMETER
MAX.
UNIT
V
DS
I
D
P
tot
T
j
R
DS(ON)
Drain-source voltage
Drain current (DC)
Total power dissipation
Junction temperature
Drain-source on-state
resistance;
60
41
125
175
38
V
A
W
C
m
V
GS
= 5 V
PINNING - TO220AB
PIN CONFIGURATION
SYMBOL
PIN
DESCRIPTION
1
gate
2
drain
3
source
tab
drain
LIMITING VALUES
Limiting values in accordance with the Absolute Maximum System (IEC 134)
SYMBOL
V
DS
V
DGR
±
V
GS
±
V
GSM
PARAMETER
Drain-source voltage
Drain-gate voltage
Gate-source voltage
Non-repetitive gate-source
voltage
Drain current (DC)
Drain current (DC)
Drain current (pulse peak value)
Total power dissipation
Storage temperature
Junction Temperature
CONDITIONS
-
R
GS
= 20 k
-
t
p
≤
50
μ
s
MIN.
-
-
-
-
MAX.
60
60
15
20
UNIT
V
V
V
V
I
D
I
D
I
DM
P
tot
T
stg
T
j
T
mb
= 25 C
T
mb
= 100 C
T
mb
= 25 C
T
mb
= 25 C
-
-
-
-
-
-
41
29
164
125
175
175
A
A
A
W
C
C
- 55
-
THERMAL RESISTANCES
SYMBOL
R
th j-mb
PARAMETER
Thermal resistance junction to
mounting base
Thermal resistance junction to
ambient
CONDITIONS
TYP.
-
MAX.
1.2
UNIT
K/W
R
th j-a
60
-
K/W
d
g
s
1 2 3
tab
August 1994
1
Rev 1.000
