Philips Semiconductors
Product data
CBT16211
24-bit bus switch with 12-bit output enables
2001 Jun 13
4
ABSOLUTE MAXIMUM RATINGS
1, 2
SYMBOL
PARAMETER
CONDITIONS
RATING
UNIT
V
CC
I
IK
V
I
V
OUT
I
OUT
T
stg
DC supply voltage
–0.5 to +7.0
V
DC input diode current
DC input voltage
3
DC output voltage
3
V
I
< 0
–50
mA
–0.5 to +7.0
V
output in Off or High state
–0.5 to +5.5
V
DC output current
output in Low state
128
mA
°
C
Storage temperature range
–65 to 150
NOTES:
1. Stresses beyond those listed may cause permanent damage to the device. These are stress ratings only and functional operation of the
device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to
absolute-maximum-rated conditions for extended periods may affect device reliability.
2. The performance capability of a high-performance integrated circuit in conjunction with its thermal environment can create junction
temperatures which are detrimental to reliability. The maximum junction temperature of this integrated circuit should not exceed 150
°
C.
3. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.
RECOMMENDED OPERATING CONDITIONS
SYMBOL
PARAMETER
LIMITS
UNIT
Min
4.5
Max
5.5
V
CC
V
IH
V
IL
T
amb
DC supply voltage
V
High-level input voltage
2.0
V
Low-level Input voltage
0.8
V
°
C
Operating free-air temperature range
–40
+85
DC ELECTRICAL CHARACTERISTICS
LIMITS
SYMBOL
PARAMETER
TEST CONDITIONS
T
amb
= –40 to +85
°
C
Min
Typ
1
UNIT
Max
V
IK
V
P
Input clamp voltage
V
CC
= 4.5 V; I
I
= –18 mA
V
IN
= V
CC
= 5.0 V; I
OUT
= –100
μ
A
V
CC
= 0 V; V
I
= 5.5 V
V
CC
= 5.5 V; V
I
= GND or 5.5 V
V
CC
= 5.5 V; I
O
= 0, V
I
= V
CC
or GND
V
CC
= 5.5 V, one input at 3.4 V,
other inputs at V
CC
or GND
V
I
= 3 V or 0
V
O
= 3 V or 0, OE = V
CC
V
CC
= 4.0 V; V
1
= 2.4 V; I
I
= 15 mA
V
CC
= 4.5 V; V
1
= 0 V; I
I
= 64 mA
V
CC
= 4.5 V; V
1
= 0 V; I
I
= 30 mA
V
CC
= 4.5 V; V
1
= 2.4 V; I
I
= –15 mA
–1.2
V
Output high pass voltage
3.4
3.6
3.9
V
I
I
Input leakage current
10
±
1
3
μ
A
I
CC
Quiescent supply current
μ
A
I
CC
Additional supply current per
input pin
2
Control pins
2.5
mA
C
I
4.5
pF
C
I(OFF)
Port OFF capacitance
6.9
pF
14
20
r
on3
5
7
5
7
8
12
NOTES:
1. All typical values are at V
= 5 V, T
= 25
°
C.
2. This is the increase in supply current for each input that is at the specified TTL voltage level rather than V
CC
or GND.
3. Measured by the voltage drop between the A and the B terminals at the indicated current through the switch.
On-state resistance is determined by the lowest voltage of the two (A or B) terminals.
