| 型號： | CP-AD306 |
| 元件分類： | RF連接器 |
| 英文描述： | FEMALE-MALE, RF RIGHT ANGLED ADAPTER, JACK-PLUG |
| 文件頁數： | 2/2頁 |
| 文件大?。?/td> | 98K |
| 代理商： | CP-AD306 |
Cambridge Products, P.O. Box 1732, Waseca, MN 56093-0832 1-800-24
3-8814 Fax: 507-833-6287 www.cambridgeproducts.com
INCHES (MILLIMETERS)
CUSTOMER DRAWINGS AVAILABLE UPON REQUEST
Electrical Characteristics
Impedance: 50 Ohm nominal (except where noted)
Frequency range: 0-11 GHz
Working voltage: 500 volts RMS at sea level
Dielectric withstanding voltage: 1500 volts RMS at sea level
Corona level: 375 volts minimum at 70,000 feet
Contact resistance:
Outer - 0.2 milliohms maximum
Center - 2.1 milliohms maximum
Insulation resistance: 5000 megohms minimum
Environmental Characteristics
Recommended temperature range: -55OC to +85OC
Moisture Resistance: MIL-STD-202
Mechanical Characteristics
Durability: 500 cycles
Cable retention: 20 lbs., RG-58 C/U cable
Materials
Body and coupling nut: Zinc or brass
Contact: Beryllium copper, phosphor bronze or brass
Crimp Sleeve: Brass
Insulator: Teflon, TPX or Delrin
Hardware: Brass
Plating: Body - Nickel
Crimp sleeve - Nickel
Hardware - Nickel
Contact - Gold
* These values are typical and may not apply to all connectors.
The TNC connector is a threaded version of the BNC mating interface. All contacts
are captivated for ruggedness. The TNC is a commercial quality connector that
provides additional retention for shock and vibration applications. The TNC con-
nector intermates with all standard 50 Ohm TNC connectors.
TNC Connectors
Specifications
Specifications*
