Cambridge Products, P.O. Box 1732, Waseca, MN 56093-0832 1-800-243-8814 Fax: 507-833-6287 www.cambridgeproducts.com
INCHES (MILLIMETERS)
CUSTOMER DRAWINGS AVAILABLE UPON REQUEST
Electrical Characteristics
Impedance: 50 Ohm nominal
Frequency range: 0-11 GHz
Working voltage: 500 volts RMS at sea level
Dielectric withstanding voltage: 1500 volts RMS at sea level
Corona level: 375 volts minimum at 70,000 feet
Contact resistance:
Outer - 0.2 milliohms maximum
Center - 2.1 milliohms maximum
Insulation resistance: 5000 megohms minimum
Environmental Characteristics
Recommended temperature range: -65OC to +165OC
Moisture Resistance: MIL-STD-202
Mechanical Characteristics
Durability: 500 cycles
Cable retention: 20 lbs., RG-58 C/U cable
Materials
Body and coupling nut: Brass
Contact: Brass, phosphor bronze or beryllium copper
Crimp sleeve: Brass
Insulator: Teflon or Delrin
Hardware: Brass
Plating: Body - Nickel
Crimp sleeve - Nickel
Hardware - Nickel
Contact - Gold
The N connector employs a large diameter threaded interface for excellent strength
and reliability. This commercial quality connector handles high power applications
such as antenna feeds for radios and cell sites. Termination options include crimp
and clamp styles for rugged service.
* These are typical and may not apply to all connectors.
N Connectors
Specifications
