DC/DC Converters
ctparts.com
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322 Inside US
949-453-1811 Outside US
Copyright 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
CENTRAL Technologies
SPECIFICATIONS
Vin
Iout
Effi.
Part
Nom.
Input Range
Vout
Max.
Min.
Typ.
Number
(VDC)
(mA)
(%)
CTDD1907SF-0505-SU1K-2
5
4.5-5.5
5
400
40
81
CTDD1907SF-0509-SU1K-2
5
4.5-5.5
9
222
23
82
CTDD1907SF-0512-SU1K-2
5
4.5-5.5
12
167
17
84
CTDD1907SF-0515-SU1K-2
5
4.5-5.5
15
133
14
84
CTDD1907SF-1205-SU1K-2
12
10.8-13.2
5
400
40
82
CTDD1907SF-1209-SU1K-2
12
10.8-13.2
9
222
23
83
CTDD1907SF-1212-SU1K-2
12
10.8-13.2
12
167
17
85
CTDD1907SF-1215-SU1K-2
12
10.8-13.2
15
133
14
85
CTDD1907SF-2405-SU1K-2
24
21.6-26.4
5
400
40
83
CTDD1907SF-2409-SU1K-2
24
21.6-26.4
9
222
23
84
CTDD1907SF-2412-SU1K-2
24
21.6-26.4
12
167
17
86
CTDD1907SF-2415-SU1K-2
24
21.6-26.4
15
133
14
86
CTDD1907SF-2424-SU1K-2
24
21.6-26.4
24
83
8
86
ISOLATION SPECIFICATIONS
Item
Test Condition
MIN
TYP
MAX
Units
Isolation Voltage
Tested for 1 minute
1000
VDC
Isolation Resistance
Test at 500VDC
1000
M
Ω
OUTPUT SPECIFICATIONS
Item
Test Condition
MIN
TYP
MAX
Units
Output Power
0.2
2
W
Line regulation
For Vin change of 1%
1.2
%
Load regulation
10% to 100%
10
15
%
Output voltage accuracy
See tolerance envelope graph
Temperature drift
100% Full load
0.03
%/°C
Output ripple
20MHz Bandwidth
100
150
mVp-p
Switching frequency
Full load, nominal input
75
KHz
CTDD1907SF-SU1K-2 Series
Fixed Input Isolated & Unregulated
2W Output, Single Output
FEATURES
Efficiency: To 86%
Temperature Range: -40°C to +85°C
Isolation: 1KVDC
Package: UL94-V0
Miscellaneous: No heat sink required. No external component
required. Industry standard pinout. Miniature SIP package. Single
Output Voltage. Fully Encapsulated. Power Density up to
1.40W/cm. PCB Mounting. Footprint from 1.05cm.
Samples available.
CHARACTERISTICS
Short Circuit Protection: 1 second
Temperature Rise at Full Load: 25°C Max. 15°C Typ.
Cooling: Free air convection
No Load Power Consumption: 10% nominal power (typical)
Operating Temperature Range: -40°C to +85°C
Storage Temperature Range: -55°C to +125°C
Lead temperature: 300°C (1.5mm from case for 10 seconds)
Storage Humidity Range: < 95%
Case Material: Plastic (UL94-V0)
MTBF: >3,500,000 hours
Miscellaneous: RoHS Compliant.
Note:
1. All specifications measured at TA=25°C, humidity<75%, nominal input voltage and rated output unless
otherwise specified.
01.08.07
TYPICAL CHARACTERISTICS
+10%
Tolerance Envelope Graph
Temperature Derating Graph
Safe Operating Area
10%
50%
100%
Output Current(%)
+2.5%
120
60
40
20
0
-40
0
40
80
120
Ambient Temperature(°C)
Output
Power(%)
80
100
-2.5%
-7.5%
Typical
Load
Line
+5%
Nominal
Voltage
Output
V
olt
age(%)
RoHS
Compliant
