560H Series Connector Conforming to Ver. 4
2
Dimensions are in millimeters (inches)
www.fcai.fujitsu.com
Specifications
subject to change
RIGHT-ANGLE PLUG, THROUGHHOLE TYPE (WITH LEFT-BUTTON EJECTOR, SUNK
MOUNTING TYPE) SUPPORTS TYPE I, II CARDS
s DIMENSIONS
Part number: FCN-565P068-G/W-V4
s PC BOARD MOUNTING HOLE LAYOUT (MOUNTING SIDE)
The connector is mounted on a PC board so that only its terminal connection part rests on the board.
5.715 (0.225) ±0.05 (0.0020)
3.810 (0.15) ±0.05 (0.0020)
1.905 (0.075) ±0.05 (0.0020)
1.27 (0.05)
50.8 (2) ±0.1(0.0039)
±0.05 (0.0020)
41.91 (1.65)±0.1 (0.0039)
No.1
No.68
6.7
+0
No.2
No.3
(Card insertion side)
2- 2.8 (0.110)
68- 1 (0.039)
±0.1(0.0039)
±0.05 (0.0020)
s MOUNTING EXAMPLE
M2.5 screw
Nut
Mounting height
4.5mm(0.177in.)
Nut
Unit: mm (in.)
3 (0.118)
6 (0.236)
0.51
(0.020)
1.905
(0.075)
3.810
(0.15)
5.715
(0.225)
4.5
(0.177)
2.5 (0.098)
2.1
(0.083)
5 (0.197)
3 (0.118)
67.31 (2.65)
59.7 (2.35)
50.8 (2)
34 (1.339)
2.42
(0.095)
11.2
(0.441)
8
(0.315)
2.8
3.5
(0.138)
35.2
(1.386)
R 1.4
2- 2.8 (0.110)
83.38
(3.283)
3.7
(0.146)
10 (0.394)
When
a
card
is
ejected
When
a
card
is
inserted
11
(0.433)
78.5 (3.091)
42 (1.654)
35.5 (1.398)
7
(0.276)
2.1
(0.083)
No.68
No.35
No.1
No.34
No.17
No.51
2.5 (0.098)
5
(0.197)
4.25
(0.167)
