BCD20012-G Rev AA Ver 1.1
Page 1 of 8
www.power-one.com
FND300-1012G Front-End Data Sheet
DC Input, 12V Output, 300-Watts
Description
The FND300-1012G is a highly-efficient bus converter with one high current output, which can be used in a wide
range of applications. Passive current share along with internal ORing diodes allow this unit to be also used in
redundant, hot-swap applications.
The FND300 meets international safety standards and displays the CE Mark for the low Voltage Directive.
Model Selection
Model
Nominal
Output
Voltage
(VDC)
Input
Current
Max
(ADC)
Adjustment
Range
(VDC)
Output Rated
Current I rated
(ADC)
Output
Ripple/Noise,
mV p-p
Typical
Efficiency @
I rated %
FND300-1012G
12
10
N/A
25
<120
>80
Applications
Telecommunications equipment
Features
RoHS compliant for all six substances
40.5 to 72 VDC Input Range
12 V output
2000 VAC I/O electric strength test
Highly-efficient topology
High-density design
4" x 1.65" x 8.5" cassette
I2C interface
Supervisory signaling
Overtemperature, output overvoltage, and output
overcurrent protection
ORing diode included for true redundant operation
Safety approvals: UL60950-1/ CSA 60950-1, & TUV
EN60950-1
