Absolute Maximum Ratings
Thermal Information
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +8.0V
Input, Output or I/O Voltage . . . . . . . . . . . . GND -0.5V to VCC +0.5V
ESD Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class 1
Typical Derating Factor . . . . . . . . . . . 1mA/MHz Increase in ICCOP
Thermal Resistance (Typical)
θ
JA
θ
JC
CERDIP Package. . . . . . . . . . . . . . .
78oC/W
23oC/W
PDIP Package . . . . . . . . . . . . . . . . .
90oC/W
N/A
Storage Temperature Range . . . . . . . . . . . . . . . . . -65oC to +150oC
Maximum Junction Temperature
Ceramic Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+175oC
Plastic Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+150oC
Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . .+300oC
Die Characteristics
Gate Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .720 Gates
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
Operating Conditions
Operating Voltage Range. . . . . . . . . . . . . . . . . . . . . . +4.5V to +5.5V
Operating Temperature Range
HD-4702-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40oC to +85oC
HD-4702-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55oC to +125oC
Electrical Specifications
VCC = 5V ±10%, TA = -40
oC to +85oC (HD-4702-9), T
A = -55
oC to +125oC (HD-4702-8)
SYMBOL
PARAMETER
LIMITS
UNITS
TEST CONDITIONS
MIN
MAX
VIH
Input High Voltage
VCC 70%
-
V
VCC = 4.5V
VIL
Input Low Voltage
-
VCC 30%
V
VCC = 4.5V
VOH1
Output High Voltage
VCC -0.1
-
V
IOH ≤ -1μA, VCC = 4.5V, (Note 1)
VOL1
Output Low Voltage
-
0.1
V
IOL ≤ +1μA, VCC = 4.5V, (Note 1)
IIH
Input High Current
-1
+1
μAVIN = VCC, All 0ther Pins = 0V, VCC = 5.5V
IILX
Input Low Current
(lX Input)
-1
+1
μAVIN = 0V, All Other Pins = VCC, VCC = 5.5V
IIL
Input Low Current
(All Other Inputs)
--100
μAVIN = 0V, All Other Pins = VCC, VCC = 5.5V
(Note 2)
IOHX
Output High Current
(OX)
-0.1
-
mA
VOUT = VCC - 0.5, VCC = 4.5V, Input at 0V
or VCC per Logic Function or Truth Table
IOH1
Output High Current
(All Other Outputs)
-1.0
-
mA
VOUT = 2.5V, VCC = 4.5V, Input at 0V
or VCC per Logic Function or Truth Table
IOH2
Output High Current
(All Other Outputs)
-0.3
-
mA
VOUT = VCC -0.5, VCC = 4.5V, Input at 0V
or VCC per Logic Function or Truth Table
IOLX
Output Low Current
(OX)
0.1
-
mA
VOUT = 0.4V, VCC = 4.5V, Input at 0V
or VCC per Logic Function or Truth Table
IOL
Output Low Current
(All Other Outputs)
1.6
-
mA
VOUT = 0.4V, VCC = 4.5V Input, at 0V
or VCC per Logic Function or Truth Table
ICC
Supply Current
(Static)
-
1500
μAECP = VCC, CP = 0V, VCC = 5.5V,
All Other Inputs = GND, (Note 2)
-
1000
μAE
CP = VCC, CP = 0V, VCC = 5.5V,
All Other Inputs = VCC, (Note 2)
NOTES:
1. Interchanging of force and sense conditions is permitted.
2. Input Current and Quiescent Power Supply Current are relatively higher for this device because of active pull-up circuits on all inputs
except IX.
