HD66730/HD66731
115
V
CC
V1
V2
V3
V4
V5
V
CC
C1
C2
Vci
GND
V5OUT2
V5OUT3
R1
R1
R0
R1
R1
C1
C2
Vci
GND
V5OUT2
V5OUT3
R1
R1
R0
R1
R1
+
+
+
+
1
μ
F
+
1
μ
F
GND
GND
1
μ
F
1
μ
F
1
μ
F
GND
GND
(Double boosting)
(Triple boosting)
V
CC
V1
V2
V3
V4
V5
V
CC
Thermistor
Thermistor
Notes: 1.
2.
3.
4.
5.
6.
The reference voltage input (Vci) must be set below the power supply (V
CC
).
Current that flows into reference voltage input (Vci) is 2-3 times larger than the load current
flowing through bleeder resistors. Note that a reference voltage drop occurs due to the
current flowing into the Vci input when a reference voltage (Vci) is generated by resistor
division.
The amount of output voltage (V5OUT2/V5OUT3) drop of a booster circuit also increases
as the load current flowing through bleeder resistors increases. Thus, set the bleeder
resistance as large as possible (4.7 k
or greater) without affecting display picture quality.
Adjust the reference voltage input (Vci) according to the fluctuation of booster characteristics
because the output voltage (V5OUT2/V5OUT3) drop depends on the load current,
operation temperature, operation frequency, capacitance of external capacitors,
and manufacturing tolerance. Refer to Electrical Characteristics for details.
Adjust the reference voltage input (Vci) so that the output voltage (V5OUT2/V5OUT3)
after boosting will not exceed the absolute maximum rating of liquid crystal power supply
voltage (15V).
Make sure that you connect polarized capacitors correctly.
Figure 47 Example of Power Supply for Liquid Crystal Display Drive (with Internal Booster)
