HD74HC244
Octal Buffers/Line Drivers/Line Receivers
(with noninverted 3-state outputs)
Description
The HD74HC244 is a non-inverting buffer and has two active low enables (1
G
and 2
G
). Each enable
independently controls 4 buffers.
This device does not have schmitt trigger inputs.
Features
High Speed Operation: t
pd
= 11 ns typ (C
L
= 50 pF)
High Output Current: Fanout of 15 LSTTL Loads
Wide Operating Voltage: V
CC
= 2 to 6 V
Low Input Current: 1 μA max
Low Quiescent Supply Current: I
CC
(static) = 4 μA max (Ta = 25°C)
Function Table
Inputs
G
Output
A
Y
H
X
Z
L
H
H
L
Notes
L
L
H: high level
L: low level
X: irrelevant
Z: off (high-impedance) state of a 3-state output
