Advance Information
PowerNPTM NPe405L Embedded Processor Data Sheet
32
IICSCL
IIC Serial Clock.
I/O
5V tolerant
3.3V LVTTL
1, 2
IICSDA
IIC Serial Data.
I/O
5V tolerant
3.3V LVTTL
1, 2
Interrupts Interface
[IRQ0:6]
Interrupt Requests.
I
5V tolerant
3.3V LVTTL
1, 5
JTAG Interface
TDI
Test Data In.
I
5V tolerant
3.3V LVTTL
1, 4
TMS
Test Mode Select.
I
5V tolerant
3.3V LVTTL
1, 4
TDO
Test Data Out.
O
5V tolerant
3.3V LVTTL
TCK
Test Clock.
I
5V tolerant
3.3V LVTTL
1, 4
TRST
Test Reset.
I
5V tolerant
3.3V LVTTL
2, 5
System Interface
SysClk
Main System Clock input.
I
3.3V Analog
Wire w/ESD
SysReset
Main System Reset.
I/O
5V tolerant
3.3V LVTTL
1, 2
SysErr
Set to 1 when a Machine Check is generated.
O
5V tolerant
3.3V LVTTL
Halt
Halt from external debugger.
I
5V tolerant
3.3V LVTTL
1, 4
GPIO0
General Purpose I/O. To access this function, software
must toggle a DCR bit.
I/O
5V tolerant
3.3V LVTTL
1, 6
GPIO1:31
General Purpose I/O. To access this function, software
must toggle a DCR bit.
I/O
5V tolerant
3.3V LVTTL
1
TestEn
Test Enable. Used only for manufacturing tests. Pull down
for normal operation.
I
3.3V LVTTL
Rcvr w/ PD
3
TmrClk
This input must toggle at a rate of less than one half the
CPU core frequency (less than 100MHz in most cases). In
most cases this input toggles much slower (in the 1MHz to
10MHz range).
I
5V tolerant
3.3V LVTTL
1, 4
Signal Functional Description (Part 5 of 6)
Notes:
1. Receiver input has hysteresis
2. Must pull up (recommended value is 3k
to 3.3V, 10k to 5V)
3. Must pull down (recommended value is 1k
)
4. If not used, must pull up (recommended value is 3k
to 3.3V)
5. If not used, must pull down (recommended value is 1k
)
6. Strapping input during reset; pull-up or pull-down required
Signal Name
Description
I/O
Type
Notes
