– 8 –
ICX414AL
H
φ
2
90%
H
φ
1
two
twh
tr
tf
10%
twl
V
CR
V
HL
V
φ
H
V
φ
H
2
RG waveform
V
RGLH
V
RGLL
V
RGLm
V
RGH
tr
tf
twh
twl
V
RGL
Point A
V
φ
RG
V
SUB
(A bias generated within the CCD)
100%
90%
10%
0%
tr
tf
twh
φ
M
2
φ
M
V
φ
SUB
(3) Horizontal transfer clock waveform
Cross-point voltage for the H
φ
1
rising side of the horizontal transfer clocks H
φ
1
and H
φ
2
waveforms is V
CR
.
The overlap period for twh and twl of horizontal transfer clocks H
φ
1
and H
φ
2
is two.
(4) Reset gate clock waveform
V
RGLH
is the maximum value and V
RGLL
is the minimum value of the coupling waveform during the period from
Point A in the above diagram until the rising edge of RG.
In addition, V
RGL
is the average value of V
RGLH
and V
RGLL
.
V
RGL
= (V
RGLH
+ V
RGLL
)/2
Assuming V
RGH
is the minimum value during the interval twh, then:
V
φ
RG
= V
RGH
– V
RGL
Negative overshoot level during the falling edge of RG is V
RGLm
.
(5) Substrate clock waveform
H
φ
1
, H
φ
2
φ
RG
φ
SUB
