6.42
IDT71V2577, IDT71V2579, 128K x 36, 256K x 18, 3.3V Synchronous SRAMs with
2.5V I/O, Flow-Through Outputs, Burst Counter, Single Cycle Deselect Commercial and Industrial Temperature Ranges
Pin Definition
(1)
Symbol
NOTE:
1. All synchronous inputs must meet specified setup and hold times with respect to CLK.
Pin Function
I/O
Active
Description
A
0
-A
17
Address Inputs
I
N/A
Synchronous Address inputs. The address register is triggered by a combi-nation of the rising
edge of CLK and
ADSC
Low or
ADSP
Low and
CE
Low.
ADSC
Address Status
(Cache Controller)
I
LOW
Synchronous Address Status from Cache Controller
ADSC
is an active LOW input that is
used to load the address registers with new addresses.
ADSP
Address Status
(Processor)
I
LOW
Synchronous Address Status from Processor
ADSP
is an active LOW input that is used to
load the address registers with new addresses.
ADSP
is gated by
CE
.
ADV
Burst Address
Advance
I
LOW
Synchronous Address Advance.
ADV
is an active LOW input that is used to advance the
internal burst counter controlling burst access after the initial address is loaded. When the
input is HIGH the burst counter is not incremented; that is, there is no address advance.
BWE
Byte Write Enable
I
LOW
Synchronous byte write enable gates the byte write inputs
BW
1
-
BW
4
. If
BWE
is LOW at the
rising edge of CLK then
BW
x inputs are passed to the next stage in the circuit. If
BWE
is
HIGH then the byte write inputs are blocked and only
GW
can initiate a write cycle.
BW
1
-
BW
4
Individual Byte
Write Enables
I
LOW
Synchronous byte write enables.
BW
1
controls I/O
0-7
, I/O
P1
,
BW
2
controls I/O
8-15
, I/O
P2
, etc.
Any active byte write causes all outputs to be disabled.
CE
Chip Enable
I
LOW
Synchronous chip enable.
CE
is used with CS
0
and
CS
1
to enable the IDT71V2577/79.
CE
also gates
ADSP
.
CLK
Clock
I
N/A
This is the clock input. All timing references for the device are made with respect to this
input.
CS
0
Chip Select 0
I
HIGH
Synchronous active HIGH chip select. CS
0
is used with
CE
and
CS
1
to enable the chip.
CS
1
Chip Select 1
I
LOW
Synchronous active LOW chip select.
CS
1
is used with
CE
and CS
0
to enable the chip.
GW
Global Write
Enable
I
LOW
Synchronous global write enable. This input will write all four 9-bit data bytes when LOW on
the rising edge of CLK.
GW
supersedes individual byte write enables.
I/O
0
-I/O
31
I/O
P1
-I/O
P4
Data Input/Output
I/O
N/A
Synchronous data input/output (I/O) pins. The data input path is registered, triggered by the
rising edge of CLK. The data output path is flow-through (no output register).
LBO
Linear Burst Order
I
LOW
Asynchronous burst order selection input. When
LBO
is HIGH, the inter-leaved burst
sequence is selected. When
LBO
is LOW the Linear burst sequence is selected.
LBO
is a
static input and must not change state while the device is operating.
OE
Output Enable
I
LOW
Asynchronous output enable. When
OE
is LOW the data output drivers are enabled on the
I/O pins if the chip is also selected. When
OE
is HIGH the I/O pins are in a high-impedance
state.
V
DD
Power Supply
N/A
N/A
3.3V core power supply.
V
DDQ
Power Supply
N/A
N/A
2.5V I/O Supply.
V
SS
Ground
N/A
N/A
Ground.
NC
No Connect
N/A
N/A
NC pins are not electrically connected to the device.
ZZ
Sleep Mode
1
HIGH
Asynchronous sleep mode input. ZZ HIGH will gate the CLK internally and power down the
IDT71V2577/79 to its lowest power consumption level. Data retention is guaranteed in
Sleep Mode.
4877 tbl 02
